ULS-12/8.3-D48PM-C
ActiveMurata Power Solutions Inc.
ISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 2:1, 99.6 W, 1 OUTPUT, 12 V, 8.3 A
Deep-Dive with AI
Search across all available documentation for this part.
ULS-12/8.3-D48PM-C
ActiveMurata Power Solutions Inc.
ISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 2:1, 99.6 W, 1 OUTPUT, 12 V, 8.3 A
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | ULS-12/8.3-D48PM-C | ULS-12 Series |
|---|---|---|
| - | - | |
| Applications | ITE (Commercial) | ITE (Commercial) |
| Control Features | Active High, Enable | Active High, Enable, Active Low |
| Current - Output (Max) [Max] | 8.3 A | 2.5 - 8.3 A |
| Efficiency | 92 % | 87.7 - 92 % |
| Features | OVP, Remote On/Off, SCP, OTP, UVLO | OVP, Remote On/Off, SCP, OTP, UVLO |
| Mounting Type | Surface Mount | Surface Mount, Through Hole |
| Number of Outputs | 1 | 1 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 1/16 Brick, 8-SMD Module | 1/16 Brick, 8-SMD Module, 8-DIP Module, 1/16 Brick |
| Power (Watts) | 100 W | 30 - 100 W |
| Size / Dimension | - | 9.1 mm |
| Size / Dimension | - | 22.9 mm |
| Size / Dimension [x] | 1.3 " | 1.3 " |
| Size / Dimension [x] | 33 mm | 33 mm |
| Size / Dimension [y] | 22.9 mm | 22.9 mm |
| Size / Dimension [y] | 0.9 " | 0.9 " |
| Size / Dimension [z] | 0.4 " | 0.36 - 0.4 " |
| Size / Dimension [z] | 10.2 mm | 10.2 mm |
| Type | Isolated Module | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V | 75 V |
| Voltage - Input (Min) [Min] | 36 V | 36 V |
| Voltage - Isolation | 2250 VDC | 2250 VDC |
| Voltage - Output 1 | 12 V | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 200 | $ 37.46 | |
ULS-12 Series
ISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 2:1, 99.6 W, 1 OUTPUT, 12 V, 8.3 A
| Part | Power (Watts) | Applications | Mounting Type | Current - Output (Max) [Max] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Voltage - Input (Min) [Min] | Number of Outputs | Efficiency | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Isolation | Features | Voltage - Output 1 | Type | Control Features | Voltage - Input (Max) [Max] | Package / Case | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. ULS-12/8.3-D48PM-C | 100 W | ITE (Commercial) | Surface Mount | 8.3 A | 0.4 " | 10.2 mm | 22.9 mm | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 92 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active High, Enable | 75 V | 1/16 Brick, 8-SMD Module | ||
Murata Power Solutions Inc. ULS-12/5-D48NL2-C | 60 W | ITE (Commercial) | Through Hole | 5 A | 0.4 " | 10.2 mm | 22.9 mm | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 91 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active Low, Enable | 75 V | 8-DIP Module, 1/16 Brick | ||
Murata Power Solutions Inc. ULS-12/2.5-D48NL2-C | 30 W | ITE (Commercial) | Through Hole | 2.5 A | 0.36 in | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 87.7 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active Low, Enable | 75 V | 8-DIP Module, 1/16 Brick | 9.1 mm | 22.9 mm | ||
Murata Power Solutions Inc. ULS-12/5-D48P-C | 60 W | ITE (Commercial) | Through Hole | 5 A | 0.4 " | 10.2 mm | 22.9 mm | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 91 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active High, Enable | 75 V | 8-DIP Module, 1/16 Brick | ||
Murata Power Solutions Inc. ULS-12/5-D48PH-C | 60 W | ITE (Commercial) | Through Hole | 5 A | 0.4 " | 10.2 mm | 22.9 mm | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 91 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active High, Enable | 75 V | 8-DIP Module, 1/16 Brick | ||
Murata Power Solutions Inc. ULS-12/8.3-D48PM-C | ||||||||||||||||||||||||
Murata Power Solutions Inc. ULS-12/5-D48N-C | 60 W | ITE (Commercial) | Through Hole | 5 A | 0.4 " | 10.2 mm | 22.9 mm | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 91 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active Low, Enable | 75 V | 8-DIP Module, 1/16 Brick | ||
Murata Power Solutions Inc. ULS-12/8.3-D48NM-C | ||||||||||||||||||||||||
Murata Power Solutions Inc. ULS-12/8.3-D48P-C | 100 W | ITE (Commercial) | Through Hole | 8.3 A | 0.4 " | 10.2 mm | 22.9 mm | 0.9 " | 1.3 " | 33 mm | 36 V | 1 | 92 % | 85 °C | -40 °C | 2250 VDC | OTP, OVP, Remote On/Off, SCP, UVLO | 12 V | Isolated Module | Active High, Enable | 75 V | 8-DIP Module, 1/16 Brick | ||
Murata Power Solutions Inc. ULS-12/5-D48N-C |
Description
General part information
ULS-12 Series
Isolated Module DC DC Converter 1 Output 12V 8.3A 36V - 75V Input
