AP63300WU-EVM

Active

Diodes Inc

EVAL BOARD FOR AP63300

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AP63300WU-EVM

Active

Diodes Inc

EVAL BOARD FOR AP63300

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AP63300WU-EVM

Board Type	Fully Populated
Current - Output	3 A
Frequency - Switching	500 kHz
Main Purpose	DC/DC, Step Down
Outputs and Type	Non-Isolated
Outputs and Type	1
Regulator Topology	Buck
Supplied Contents	Board(s)
Utilized IC / Part	AP63300
Voltage - Input [Max]	32 V
Voltage - Input [Min]	3.8 V
Voltage - Output	5 V

AP63300 Series

3.8V-32V INPUT, 3A Low Iq Synchronous Buck with Enhanced EMI Reduction

Part	Voltage - Output	Frequency - Switching	Utilized IC / Part	Voltage - Input [Max]	Voltage - Input [Min]	Board Type	Current - Output	Outputs and Type	Outputs and Type	Regulator Topology	Main Purpose	Supplied Contents
Diodes Inc AP63300WU-EVM	5 V	500 kHz	AP63300	32 V	3.8 V	Fully Populated	3 A	Non-Isolated	1	Buck	DC/DC Step Down	Board(s)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 37.39

Description

General part information

AP63300 Series

The AP63300/AP63301 is a 3A, synchronous buck converter with a wide input voltage range of 3.8V to 32V. The device fully integrates a 75mΩ high-side power MOSFET and a 40mΩ low-side power MOSFET to provide high-efficiency step-down DC-DC conversion.
