GCQ10A06

Active

Kyocera AVX

DIODE ARR SCHOTT 60V 10A TO220-3

Search across all available documentation for this part.

Active

Kyocera AVX

DIODE ARR SCHOTT 60V 10A TO220-3

Technical Specifications

Parameters and characteristics for this part

Specification	GCQ10A06

Current - Average Rectified (Io) (per Diode)	10 A
Current - Reverse Leakage @ Vr	5 mA
Mounting Type	Through Hole
Operating Temperature - Junction [Max]	150 °C
Operating Temperature - Junction [Min]	-40 °C
Package / Case	TO-220-3
Speed	200 mA, 500 ns
Supplier Device Package	TO-220-3
Technology	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	60 V
Voltage - Forward (Vf) (Max) @ If	580 mV

Part	Voltage - Forward (Vf) (Max) @ If	Speed	Package / Case	Technology	Mounting Type	Current - Reverse Leakage @ Vr	Current - Average Rectified (Io) (per Diode)	Supplier Device Package	Voltage - DC Reverse (Vr) (Max) [Max]	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]
Kyocera AVX GCQ10A06	580 mV	200 mA 500 ns	TO-220-3	Schottky	Through Hole	5 mA	10 A	TO-220-3	60 V	150 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	2500	$ 1.05

General part information

Diode Array 60 V 10A Through Hole TO-220-3
