MSAP-03BFFA-SL8001

Active

Amphenol LTW

CONN PLUG FMALE 3POS SOLDER CUP

Search across all available documentation for this part.

Active

Amphenol LTW

CONN PLUG FMALE 3POS SOLDER CUP

Technical Specifications

Parameters and characteristics for this part

Part	Backshell Material, Plating	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Termination	Connector Type	Features	Shell Size - Insert	Orientation	Primary Material	Voltage Rating	Ingress Protection	Contact Finish - Mating	Material Flammability Rating	Contact Material	Shielding	Color	Current Rating (Amps)	Cable Opening [diameter]	Cable Opening [diameter]	Insert Material	Cable Opening [Min] [custom]	Cable Opening [Max] [custom]	Cable Opening [Min] [custom]	Cable Opening [Max] [custom]
Amphenol LTW MSAP-03BFFA-SR7001	Thermoplastic	-40 °C	105 ░C	Free Hanging (In-Line) Right Angle	Screw	Female Sockets Plug	Backshell Coupling Nut	M12-3	A	Plastic	250 VAC	IP67 - Dust Tight Waterproof	Gold	UL94 V-0	Copper Alloy	Unshielded	Black	4 A	4.5 mm 6.5 mm	0.177 in 0.256 in
Amphenol LTW MSAP-03BFFA-SL8001	Nylon Polyamide (PA)	-40 °C	105 ░C	Free Hanging (In-Line)		Female Sockets Plug	Backshell Coupling Nut	M12-3	A	Plastic	250 VDC	IP68 - Dust Tight Waterproof	Gold		Copper Alloy	Unshielded	Black				Nylon Polyamide (PA)	4 mm	0.315 in	0.157 in	8 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Plug, Female Sockets Solder Cup
