T495A106K010ATA3K8

Active

KEMET

CAP TANT 10UF 10% 10V 1206

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

T495A106K010ATA3K8

Active

KEMET

CAP TANT 10UF 10% 10V 1206

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	T495A106K010ATA3K8

Capacitance	10 µF
ESR (Equivalent Series Resistance)	3.8 Ohm
Features	Automotive
Grade	Automotive
Height - Seated (Max) [Max]	0.071 "
Height - Seated (Max) [Max]	1.8 mm
Lifetime @ Temp.	2000 Hrs
Manufacturer Size Code	A
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	1206 (3216 Metric)
Qualification	AEC-Q200
Ratings	AEC-Q200
Size / Dimension [x]	0.126 "
Size / Dimension [x]	3.2 mm
Size / Dimension [y]	0.063 in
Size / Dimension [y]	1.6 mm
Tolerance	10 %
Type	Molded
Voltage - Rated	10 V

T495A Series

Part	Mounting Type	Voltage - Rated	Package / Case	Grade	Ratings	Type	Manufacturer Size Code	Tolerance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Lifetime @ Temp.	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Qualification	Features	Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	ESR (Equivalent Series Resistance)
KEMET T495A106K010ATA3K8	Surface Mount	10 V	1206 (3216 Metric)	Automotive	AEC-Q200	Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm	AEC-Q200	Automotive	10 µF	-55 °C	125 °C	3.8 Ohm
KEMET T495A474K025ATE7K0	Surface Mount	25 VDC	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	0.47 µF	-55 °C	125 °C	7 Ohm
KEMET T495A105K035ATE3K0	Surface Mount	35 V	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	1 µF	-55 °C	125 °C	3 Ohm
KEMET T495A475K010ATE1K3	Surface Mount	10 V	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	4.7 µF	-55 °C	125 °C	1.3 Ohm
KEMET T495A685M006ATE1K8	Surface Mount	6.3 V	1206 (3216 Metric)			Molded	A	20 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	6.8 ÁF	-55 °C	125 °C	1.8 Ohm
KEMET T495A685K006ATE2K0	Surface Mount	6.3 V	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	6.8 ÁF	-55 °C	125 °C	2 Ohm
KEMET T495A225K016ATE1K8	Surface Mount	16 V	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	2.2 µF	-55 °C	125 °C	1.8 Ohm
KEMET T495A155K025ATE3K0	Surface Mount	25 VDC	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	0.15 ÁF	-55 °C	125 °C	3 Ohm
KEMET T495A685K006ATA4K5	Surface Mount	6.3 V	1206 (3216 Metric)	Automotive	AEC-Q200	Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm	AEC-Q200	Automotive	6.8 ÁF	-55 °C	125 °C	4.5 Ohm
KEMET T495A475K016ATE2K0	Surface Mount	16 V	1206 (3216 Metric)			Molded	A	10 %	0.063 in	1.6 mm	0.126 "	3.2 mm	2000 Hrs	0.071 "	1.8 mm		General Purpose	4.7 µF	-55 °C	125 °C	2 Ohm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	2000	$ 0.59

Description

General part information

T495A Series

10 µF Molded Tantalum Capacitors 10 V 1206 (3216 Metric) 3.8Ohm @ 100kHz
