MOVHE20V190Y-AP

Active

Eaton - Electronics Division

VARISTOR 190 VAC HE 20MM DISC

Search across all available documentation for this part.

Active

Eaton - Electronics Division

VARISTOR 190 VAC HE 20MM DISC

Technical Specifications

Parameters and characteristics commom to parts in this series

VARISTOR 190 VAC HE 20MM DISC

Part	Maximum AC Volts [Max]	Maximum DC Volts [Max]	Number of Circuits	Current - Surge	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Capacitance @ Frequency	Varistor Voltage (Max) [Max]	Energy	Varistor Voltage (Min) [Min]	Mounting Type	Varistor Voltage (Typ)
Eaton - Electronics Division MOVHE20V190Y-AP	190 V	250 V	1	10 kA	Disc 20mm	-40 °C	125 °C	1300 pF	330 V	210 J	270 V	Through Hole	300 V
Eaton - Electronics Division MOVHE20V250Y	250 V	320 V	1	10 kA	Disc 20mm	-40 °C	125 °C	1000 pF	429 V	275 J	351 V	Through Hole	390 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Box (TB)	500	$ 0.52

General part information

300 V 10 kA Varistor 1 Circuit Through Hole Disc 20mm
