BQ3050EVM-001
ActiveEVAL MODULE FOR BQ3050-001
Deep-Dive with AI
Search across all available documentation for this part.
BQ3050EVM-001
ActiveEVAL MODULE FOR BQ3050-001
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ3050EVM-001 | BQ3050 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion/Polymer |
| Contents | Board(s) | Board(s) |
| Fault Protection | - | Over Temperature, Over/Under Voltage, Over Current, Short Circuit |
| Function | Battery Gauge | Multi-Function Controller, Battery Gauge |
| Interface | - | SMBus |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 4 |
| Number of Cells | - | 2 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 4.4 mm |
| Package / Case | - | 38-TFSOP |
| Package / Case | - | 0.173 in |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 38-TSSOP |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ3050, BQ29440 | BQ3050, BQ29440 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| DigiKey | Box | 1 | $ 118.80 | |
| Digikey | Box | 1 | $ 118.80 | |
| Mouser Electronics | N/A | 1 | $ 118.80 | |
BQ3050 Series
SBS 1.1-compliant 2-s to 4-s battery gas gauge & protection
| Part | Interface | Package / Case | Package / Case | Package / Case | Supplier Device Package | Fault Protection | Function | Battery Chemistry | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Number of Cells [Max] [custom] | Number of Cells [Min] [custom] | Supplied Contents | Contents | Utilized IC / Part | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ3050DBTR | SMBus | 4.4 mm | 38-TFSOP | 0.173 in | 38-TSSOP | Over Current, Over Temperature, Over/Under Voltage, Short Circuit | Multi-Function Controller | Lithium Ion/Polymer | 85 °C | -40 °C | Surface Mount | 4 | 2 | ||||
Texas Instruments BQ3050EVM-001 | Battery Gauge | Board(s) | Board(s) | BQ29440, BQ3050 | Power Management | ||||||||||||
Texas Instruments BQ3050DBT | SMBus | 4.4 mm | 38-TFSOP | 0.173 in | 38-TSSOP | Over Current, Over Temperature, Over/Under Voltage, Short Circuit | Multi-Function Controller | Lithium Ion/Polymer | 85 °C | -40 °C | Surface Mount | 4 | 2 |
Description
General part information
BQ3050 Series
The Texas Instruments bq3050 Compensated End-of-Discharge Voltage (CEDV) Gas Gauge and Battery Pack Manager is a single-chip solution that provides a rich array of features for protection, authentication, and data gathering for 2-series, 3-series, and 4-series cell Li-Ion and Li-Polymer battery packs.
Using its integrated high-performance analog peripherals, the bq3050 device measures and maintains an accurate record of available capacity, voltage, current, temperature, and other critical parameters in Li-Ion or Li-Polymer batteries, and reports this information to the system host controller over an SMBus v1.1 compatible interface.
The bq3050 provides software-based 1st-level and 2nd-level safety protection for overvoltage, undervoltage, overtemperature, and overcharge conditions, as well as hardware-based protection for overcurrent in discharge and short circuit in charge and discharge conditions.
Documents
Technical documentation and resources
