22CC16A0062B

Active

Essentra Access Solutions

FASTENER, SCREW MOUNT CABLE CLAMP, 0.063 ", NYLON 6.6 (POLYAMIDE 6.6), BLACK, 0.156 "

Search across all available documentation for this part.

Active

Essentra Access Solutions

FASTENER, SCREW MOUNT CABLE CLAMP, 0.063 ", NYLON 6.6 (POLYAMIDE 6.6), BLACK, 0.156 "

Technical Specifications

Parameters and characteristics for this part

Specification	22CC16A0062B

Color	Black
Material	Polyamide (PA66), Nylon 6/6
Material Flammability Rating	UL94 V-2
Material Thickness	0.76 mm
Material Thickness	0.03 in
Mounting Type	Fastener
Opening Size	0.063 in
Opening Size	1.6 mm
Panel Hole Size	0.096 in
Panel Hole Size	2.44 mm
Type	Clamp, P-Type
Width [y]	3.96 mm
Width [y]	0.156 in

Part	Material	Color	Material Flammability Rating	Mounting Type	Panel Hole Size	Panel Hole Size	Type	Material Thickness	Material Thickness	Opening Size	Opening Size	Width [y]	Width [y]	Opening Size [custom]	Opening Size [custom]
Essentra Access Solutions 22CC16A0062B	Polyamide (PA66) Nylon 6/6	Black	UL94 V-2	Fastener	0.096 in	2.44 mm	Clamp P-Type	0.76 mm	0.03 in	0.063 in	1.6 mm	3.96 mm	0.156 in
Essentra Access Solutions 22CC16A0187	Polyamide (PA66) Nylon 6/6	Natural	UL94 V-2	Fastener	0.096 in	2.44 mm	Clamp P-Type	0.76 mm	0.03 in			3.96 mm	0.156 in	0.187 in	4.75 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Clamp, P-Type Black Fastener 0.063" (1.60mm)
