T 3260 551

Active

Amphenol Tuchel Industrial

CONN PLUG HSNG MALE 3POS INLINE

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN PLUG HSNG MALE 3POS INLINE

Technical Specifications

Parameters and characteristics for this part

Specification	T 3260 551

Connector Type	Plug Housing
Contact Shape	Circular
Contact Size	1.5 mm
Contact Type	Crimp
Features	Cable Clamp, Strain Relief, Coupling Nut
Housing Color	Silver
Ingress Protection	IP40
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Shell Finish	Nickel
Shell Material	Die Cast
Shell Size - Insert	M16-3
Shielding	Shielded
Type	For Male Pins

Part	Shell Size - Insert	Orientation	Features	Color	Shell Material	Shell Finish	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Ingress Protection	Mounting Type	Voltage Rating	Shielding	Current Rating (Amps)	Contact Finish - Mating	Primary Material	Contact Size	Note	Housing Color	Contact Type	Contact Shape	Type	Insert Material	Material Flammability Rating
Amphenol Tuchel Industrial T 3260 013	M16-3	Keyed	Strain Relief	Silver	Die Cast	Nickel	Male Pins Plug	100 °C	-40 °C	IP40	Free Hanging (In-Line)	250 VDC	Shielded	10 A	Silver	Metal
Amphenol Tuchel Industrial T 3260 002	M16-3	Keyed	Cable Clamp Strain Relief	Silver	Die Cast	Nickel	Male Pins Plug	100 °C	-40 °C	IP40	Free Hanging (In-Line)	250 VDC	Shielded	10 A	Silver	Metal
Amphenol Tuchel Industrial T 3260 551	M16-3	Keyed	Cable Clamp Coupling Nut Strain Relief		Die Cast	Nickel	Plug Housing	100 °C	-40 °C	IP40	Free Hanging (In-Line)		Shielded				1.5 mm	Contacts Not Included	Silver	Crimp	Circular	For Male Pins	Thermoplastic	UL94 V-0
Amphenol Tuchel Industrial T 3260 004	M16-3	Keyed	Cable Clamp Strain Relief	Silver	Die Cast	Nickel	Male Pins Plug	100 °C	-40 °C	IP40	Free Hanging (In-Line)	250 VDC	Shielded	10 A	Silver	Metal
Amphenol Tuchel Industrial T 3260 028	M16-3	Keyed	Cable Clamp Strain Relief	Silver	Die Cast	Nickel	Male Pins Plug	100 °C	-40 °C	IP40	Free Hanging (In-Line)	250 VDC	Shielded	10 A	Gold	Metal

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 8.24

General part information

3 Position Circular Connector Plug Housing Free Hanging (In-Line) Cable Clamp, Coupling Nut, Strain Relief
