9154 290U1000 - MFG_9154-290U1000.jpg

9154 290U1000

Active
Belden Inc.

CABLE 2COND 20AWG BEI SHLD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsCabling Solutions for Industrial ApplicationsDatasheet
9154 290U1000 - MFG_9154-290U1000.jpg

9154 290U1000

Active
Belden Inc.

CABLE 2COND 20AWG BEI SHLD

Deep-Dive with AI

DocumentsCabling Solutions for Industrial ApplicationsDatasheet

Technical Specifications

Parameters and characteristics for this part

Specification9154 290U1000
Cable TypeMulti-Conductor
Conductor InsulationPoly-Vinyl Chloride (PVC)
Conductor MaterialCopper, Tinned
Conductor Strand [custom]28
Conductor Strand [custom]7
FeaturesDrain Wire
Jacket (Insulation) Diameter [diameter]0.198 in
Jacket (Insulation) Diameter [diameter]5.03 mm
Jacket (Insulation) MaterialPoly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness0.031 in
Jacket (Insulation) Thickness0.787 mm
Jacket ColorBeige
Length1000 ft
Length304.8 m
Number of Conductors2
Operating Temperature [Max]80 C
Operating Temperature [Min]-20 C
RatingsUL Style 2464
Shield Coverage100 %
Shield MaterialAluminum
Shield TypeFoil
UsageAudio, Instrumentation, Control
Voltage300 V
Wire Gauge20 AWG

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeySpool 1000$ 1.76

Description

General part information

9154 Series

2 (1 Pair Twisted) Conductor Multi-Conductor Cable Beige 20 AWG Foil 1000.0' (304.8m)
