AR 24-ST/T
ActiveAssmann WSW Components
PIN HEADER DIL-SYSTEM, PIN: 11.9
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AR 24-ST/T
ActiveAssmann WSW Components
PIN HEADER DIL-SYSTEM, PIN: 11.9
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AR 24-ST/T |
|---|---|
| Color | Black |
| Connector Type | DIP, DIL - Header |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Mounting Type | Through Hole |
| Number of Positions | 24 |
| Number of Rows | 2 |
| Pitch [x] | 2.54 mm |
| Pitch [x] | 0.1 in |
| Row Spacing | 0.6 in |
| Row Spacing | 15.24 mm |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 1.16 | |
| 19 | $ 0.98 | |||
| 38 | $ 0.94 | |||
| 57 | $ 0.92 | |||
| 114 | $ 0.88 | |||
| 266 | $ 0.80 | |||
| 513 | $ 0.72 | |||
| 1007 | $ 0.64 | |||
| 2508 | $ 0.58 | |||
Description
General part information
AR 24-ST Series
24 Position DIP, DIL - Header Connector Post Gold
