Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1 | $ 1650.18 | |
| 2 | $ 1567.82 | |||
| 3 | $ 1521.20 | |||
General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable White 23 AWG 500.0' (152.4m)
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 10GX13 0091000 |
|---|---|
| Cable Type | Multi-Pair, Cat6a |
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP) |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Features | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.295 in |
| Jacket (Insulation) Diameter [diameter] | 7.49 mm |
| Jacket (Insulation) Material | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum |
| Length | 1 ft, 1000 ft |
| Length | 300 mm, 304.8 m |
| Length [x] | 30.5 m, 152.4 m, 7.62 m |
| Length [x] | 100 ft, 500 ', 25 ft |
| Number of Conductors | 8 |
| Ratings | UL Style CMP |
| Usage | Network |
| Voltage | 300 V |
| Wire Gauge | 23 AWG |
CABLE CAT6A 8COND 23AWG WHT 500'
| Part | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Ratings | Conductor Material | Length | Length | Usage | Wire Gauge | Length [x] | Length [x] | Conductor Strand | Cable Type | Conductor Insulation | Number of Conductors | Jacket (Insulation) Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GX13 0091000 | 0.295 in | 7.49 mm | 300 V | UL Style CMP | Copper, Bare | 1 ft, 1000 ft | 300 mm, 304.8 m | Network | 23 AWG | 7.62 m, 30.5 m, 152.4 m | 25 ft, 100 ft, 500 ' | Solid | Multi-Pair, Cat6a | Fluorinated Ethylene-Propylene (FEP) | 8 | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | Rip Cord |
