ABB-04RMMS-LC7001

Active

Amphenol LTW

CERES, STANDARD SIZE, PLASTIC, 10A, 04 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, 2 POINTS LOCK, SOLDER, RECEPTACLE, IP67 ROH

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, STANDARD SIZE, PLASTIC, 10A, 04 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, 2 POINTS LOCK, SOLDER, RECEPTACLE, IP67 ROH

Technical Specifications

Parameters and characteristics for this part

Specification	ABB-04RMMS-LC7001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Fastening Type	Bayonet Lock
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Rear Side Nut
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Finish	Nickel
Shell Size - Insert	B
Shielding	Unshielded
Voltage Rating	300 VDC

Part	Voltage Rating	Connector Type	Fastening Type	Shell Size - Insert	Ingress Protection	Contact Material	Shielding	Current Rating (Amps)	Insert Material	Shell Finish	Color	Number of Positions	Mounting Feature	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Orientation	Material Flammability Rating	Primary Material
Amphenol LTW ABB-04RMMS-LC7001	300 VDC	Male Pins Receptacle	Bayonet Lock	B	IP67 - Dust Tight Waterproof	Copper Alloy	Unshielded	10 A	Polyamide (PA) Nylon Glass Filled	Nickel	Black	4	Bulkhead - Rear Side Nut	-40 °C	105 ░C	Gold	Keyed	UL94 V-0	Plastic

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Receptacle, Male Pins Solder Cup
