ECMA-L11855S3

Obsolete

Delta Electronics/Industrial Automation

SERVOMOTOR 1500 RPM 400V

Deep-Dive with AI

Search across all available documentation for this part.

ECMA-L11855S3

Obsolete

Delta Electronics/Industrial Automation

SERVOMOTOR 1500 RPM 400V

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ECMA-L11855S3	ECMA-L Series

Approval Agency	CE, cURus	CE, cURus
Diameter - Shaft	-	35 mm
Diameter - Shaft [diameter]	1.654 in	1.654 in
Diameter - Shaft [diameter]	42 mm	1.378 - 42 mm
Encoder Type	Incremental	Incremental
Features	Oil Seal, Key, Brake	Key, Oil Seal, Brake
Function	Servomotor	Servomotor
Length - Shaft and Bearing [x]	4.449 in	3.11 - 4.449 in
Length - Shaft and Bearing [x]	113 mm	79 - 113 mm
Mounting Hole Spacing	7.874 "	7.874 "
Mounting Hole Spacing	200 mm	200 mm
Operating Temperature [Max]	40 °C	40 °C
Operating Temperature [Min]	0 °C	0 °C
Power - Rated	5.5 kW	3 - 7.5 kW
RPM	1500 RPM	1500 RPM
Size / Dimension [x]	180 mm	180 mm
Size / Dimension [x]	7.087 "	7.087 "
Size / Dimension [y]	180 mm	180 mm
Size / Dimension [y]	7.087 in	7.087 in
Termination Style	Cable with Connector	Cable with Connector
Torque - Max Momentary (oz-in / mNm)	12395 oz-in	8113 - 16903 oz-in
Torque - Max Momentary (oz-in / mNm)	87530 mNm	57290 - 119360 mNm
Torque - Rated (oz-in / mNm)	35000 mNm	2705 - 47740 mNm
Torque - Rated (oz-in / mNm)	4956 oz-in	4956 - 6761 oz-in
Torque - Rated (oz-in / mNm)	-	19100 mNm
Type	AC Motor	AC Motor
Voltage - Rated	400 VAC	400 VAC

ECMA-L Series

SERVOMOTOR 1500 RPM 400V

Part	Length - Shaft and Bearing [x]	Length - Shaft and Bearing [x]	Type	Torque - Max Momentary (oz-in / mNm)	Torque - Max Momentary (oz-in / mNm)	Mounting Hole Spacing	Mounting Hole Spacing	RPM	Voltage - Rated	Function	Approval Agency	Features	Termination Style	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Encoder Type	Diameter - Shaft [diameter]	Diameter - Shaft [diameter]	Power - Rated	Operating Temperature [Max]	Torque - Rated (oz-in / mNm)	Torque - Rated (oz-in / mNm)	Diameter - Shaft [diameter]	Torque - Rated (oz-in / mNm)
Delta Electronics/Industrial Automation ECMA-L11875R3	4.449 in	113 mm	AC Motor	119360 mNm	16903 oz-in	7.874 "	200 mm	1500 RPM	400 VAC	Servomotor	CE, cURus	Key, Oil Seal	Cable with Connector	180 mm	180 mm	7.087 in	7.087 "	Incremental	1.654 in	42 mm	7.5 kW	40 °C	6761 oz-in	47740 mNm
Delta Electronics/Industrial Automation ECMA-L11855S3	4.449 in	113 mm	AC Motor	87530 mNm	12395 oz-in	7.874 "	200 mm	1500 RPM	400 VAC	Servomotor	CE, cURus	Brake, Key, Oil Seal	Cable with Connector	180 mm	180 mm	7.087 in	7.087 "	Incremental	1.654 in	42 mm	5.5 kW	40 °C	4956 oz-in	35000 mNm
Delta Electronics/Industrial Automation ECMA-L11875S3	4.449 in	113 mm	AC Motor	119360 mNm	16903 oz-in	7.874 "	200 mm	1500 RPM	400 VAC	Servomotor	CE, cURus	Brake, Key, Oil Seal	Cable with Connector	180 mm	180 mm	7.087 in	7.087 "	Incremental	1.654 in	42 mm	7.5 kW	40 °C	6761 oz-in	47740 mNm
Delta Electronics/Industrial Automation ECMA-L11830RS	3.11 in	79 mm	AC Motor	57290 mNm	8113 oz-in	7.874 "	200 mm	1500 RPM	400 VAC	Servomotor	CE, cURus	Key, Oil Seal	Cable with Connector	180 mm	180 mm	7.087 in	7.087 "	Incremental		1.378 in	3 kW	40 °C		2705 oz-in	35 mm	19100 mNm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

ECMA-L Series

AC Motor Servomotor 1500 RPM 5.5kW Incremental 400VAC
