ATSAMC21MOTOR

Active

Microchip Technology

ATSAMC21MOTOR MICROCHIP TECHNOLOGY EMBEDDED SYSTEM DEVELOPMENT BOARDS & STARTER KIT ATSAMC21J18A MICROCONTROLLER - ARROW.COM

Deep-Dive with AI

DocumentsDatasheet Product Change Notice EN

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Arrow	N/A	1	$ 86.80
Digikey	Bulk	1	$ 84.74
Newark	Each	1	$ 67.84

Description

General part information

ATSAMC21 Series

The Microchip SAM C series of 5V Cortex M0+ devices is designed for industrial and commercial applications in noisy environments. These products feature robust communications peripherals including the SERCOM module and CAN-FD, along with advanced motor control peripherals, and the Peripheral Touch Control (PTC) for developing robust user interfaces.

Supported by MPLAB X IDE and [MPLAB Harmony](https://www.microchip.com/en-us/tools-resources/configure/mplab-harmony).

**Functional Safety**
