ESU476M450AM3AA

Active

KEMET

CAP ALUM 47UF 20% 450V RADIAL TH

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 47UF 20% 450V RADIAL TH

Technical Specifications

Parameters and characteristics for this part

Specification	ESU476M450AM3AA

Applications	General Purpose
Capacitance	47 µF
Height - Seated (Max) [Max] [z]	38 mm
Height - Seated (Max) [Max] [z]	1.496 in
Lead Spacing	7.5 mm
Lead Spacing	0.295 in
Lifetime @ Temp.	12000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can
Polarization	Polar
Ripple Current @ High Frequency	880 mA
Ripple Current @ Low Frequency	440 mA
Size / Dimension [diameter]	0.63 in
Size / Dimension [diameter]	16 mm
Tolerance	20 %
Voltage - Rated	450 V

Part	Tolerance	Voltage - Rated	Polarization	Capacitance	Ripple Current @ Low Frequency	Ripple Current @ High Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Lifetime @ Temp.	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Applications
KEMET ESU476M450AM3AA	20 %	450 V	Polar	47 µF	440 mA	880 mA	0.63 in	16 mm	Through Hole	7.5 mm	0.295 in	-25 °C	105 ░C	Radial Can	12000 Hrs	38 mm	1.496 in	General Purpose

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

47 µF 450 V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C
