Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 3.00 | |
| 10 | $ 2.71 | |||
| 25 | $ 2.61 | |||
| 50 | $ 2.53 | |||
| 100 | $ 2.45 | |||
| 250 | $ 2.36 | |||
| 500 | $ 2.29 | |||
| 1000 | $ 2.22 | |||
General part information
ROTARY SHAFT SEAL GRAY
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | N9030X1/4 2 | N9030X1 Series |
|---|---|---|
| Actuator Diameter | 6.35 mm | 6.35 mm |
| Actuator Diameter | - | 3.18 mm |
| Actuator Diameter [diameter] | 0.25 in | 0.125 - 0.25 in |
| Color | Gray | Gray |
| Features | - | Shielded |
| For Use With/Related Products | Multiple Series | Multiple Series |
| Ingress Protection | IP66/IP68 | IP66/IP68 |
| Material | Silicone Rubber | Silicone Rubber |
| Mounting Feature | Front of Panel | Front of Panel |
| Operating Temperature [Max] | 204 °C | 204 °C |
| Operating Temperature [Min] | -70 °C | -70 °C |
| Size / Dimension [z] | 0.219 in | 0.219 in |
| Size / Dimension [z] | 5.56 mm | 5.56 mm |
| Thread Size | 3/8-32 NEF-2B | 3/8-32 NEF-2B |
| Type | Rotary Shaft Seal | Rotary Shaft Seal |
ROTARY SHAFT SEAL GRAY
| Part | For Use With/Related Products | Type | Color | Mounting Feature | Actuator Diameter | Actuator Diameter [diameter] | Features | Thread Size | Ingress Protection | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [z] | Size / Dimension [z] | Material | Actuator Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
APM HEXSEAL N9030X1/4 RFI 2 | Multiple Series | Rotary Shaft Seal | Gray | Front of Panel | 6.35 mm | 0.25 in | Shielded | 3/8-32 NEF-2B | IP66/IP68 | 204 °C | -70 °C | 0.219 in | 5.56 mm | Silicone Rubber | |
APM HEXSEAL N9030X1/4 2 | Multiple Series | Rotary Shaft Seal | Gray | Front of Panel | 6.35 mm | 0.25 in | 3/8-32 NEF-2B | IP66/IP68 | 204 °C | -70 °C | 0.219 in | 5.56 mm | Silicone Rubber | ||
APM HEXSEAL N9030X1/8 2 | Multiple Series | Rotary Shaft Seal | Gray | Front of Panel | 0.125 in | 3/8-32 NEF-2B | IP66/IP68 | 204 °C | -70 °C | 0.219 in | 5.56 mm | Silicone Rubber | 3.18 mm |
