2332-40MG00DPT1-S
ActiveOupiin
BOARD TO BOARD, 40 PIN, MALE CON
Deep-Dive with AI
Search across all available documentation for this part.
2332-40MG00DPT1-S
ActiveOupiin
BOARD TO BOARD, 40 PIN, MALE CON
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 2332-40MG00DPT1-S |
|---|---|
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Features | Board Guide |
| Height Above Board | 0.094 " |
| Height Above Board | 2.4 mm |
| Mated Stacking Heights | 3.5 mm, 4.5 mm, 4 mm, 5 mm |
| Mounting Type | Surface Mount |
| Number of Positions | 40 |
| Number of Rows | 2 |
| Pitch [x] | 0.5 mm |
| Pitch [x] | 0.02 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 1.01 | |
| 200 | $ 0.84 | |||
| 400 | $ 0.68 | |||
| 600 | $ 0.57 | |||
| 800 | $ 0.51 | |||
Description
General part information
2332-40 Series
40 Position Connector Plug, Center Strip Contacts Surface Mount Gold
Documents
Technical documentation and resources
No documents available
