Specification	AT83C5136DXN-TIRUL

Connectivity	EMI, USART, UART, EBI, I2C, SPI, USB
Core Processor	80C52
Core Size (Bit Width)	8 Bit
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Oscillator Type	Internal
Peripherals	PWM, WDT, LED, POR
Program Memory Depth	32 K
Program Memory Size	32 KB
Program Memory Type	FLASH
Program Memory Width	8 bit
RAM Size Depth	1 K
RAM Size Width	8 bit
Speed	48 MHz
Voltage - Supply (Vcc/Vdd) Maximum	3.6 V
Voltage - Supply (Vcc/Vdd) Minimum	2.7 V

AT83C5136 Series

Part	Core Processor	Speed	Peripherals	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	RAM Size Depth	RAM Size Width	Core Size (Bit Width)	Oscillator Type	Connectivity	Operating Temperature (Max)	Operating Temperature (Min)	Program Memory Type	Program Memory Size	Program Memory Width	Program Memory Depth
Atmel AT83C5136DXN-TIRUL	80C52	48 MHz	LED POR PWM WDT	3.6 V	2.7 V	1 K	8 bit	8 Bit	Internal	EBI EMI I2C SPI UART USART USB	85 °C	-40 °C	FLASH	32 KB	8 bit	32 K

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources

No documents available
