Specification	ERM8-025-01-S-D-RA-L-TR

Connector Type	Header, Center Strip Contacts
Contact Finish	Gold
Contact Finish Thickness	30 µin
Features	Mounting Flange, Latches, Board Guide
Height Above Board	0.246 in
Mounting Type	Right Angle, Surface Mount
Number of Positions	50
Number of Rows	2
Pitch	0.031 in

ERM8-025 Series

Part	Pitch	Contact Finish	Mounting Type	Connector Type	Height Above Board	Contact Finish Thickness	Features	Number of Rows	Number of Positions	Mated Stacking Height Options
Samtec Inc. ERM8-025-03-S-D-RA-L-K-TR	0.031 in	Gold	Right Angle Surface Mount	Center Strip Contacts Header	0.246 in	30 µin	Board Guide Latches Mounting Flange Pick and Place	2	50
Samtec Inc. ERM8-025-01-L-D-RA-L-TR	0.031 in	Gold	Right Angle Surface Mount	Center Strip Contacts Header	0.246 in	10 Ąin	Board Guide Latches Mounting Flange	2	50
Samtec Inc. ERM8-025-09.0-S-DV-K-TR	0.031 in	Gold	Surface Mount	Center Strip Contacts Header	0.508 in	30 µin	Board Guide Pick and Place	2	50	14mm 16mm 19mm
Samtec Inc. ERM8-025-02.0-S-DV-P-TR	0.031 in	Gold	Surface Mount	Center Strip Contacts Header	0.235 in	30 µin	Board Guide Pick and Place	2	50	12mm 7mm 9mm
Samtec Inc. ERM8-025-05.0-S-DV-L-TR	0.031 in	Gold	Surface Mount	Center Strip Contacts Header	0.351 in	30 µin	Board Guide Latches	2	50	10mm 12mm 15mm
Samtec Inc. ERM8-025-01-S-D-RA-DS-TR	0.031 in	Gold	Right Angle Surface Mount	Differential Pair Array MALE	0.246 in	30 µin	Board Guide Mounting Flange	2	50
Samtec Inc. ERM8-025-05.0-L-DV-DSS-K-TR	0.031 in	Gold	Surface Mount	Differential Pair Array MALE	0.351 in	10 Ąin	Board Guide Mating Guide Pick and Place	2	50	10mm 12mm 15mm
Samtec Inc. ERM8-025-01-L-D-RA-DS-TR	0.031 in	Gold	Right Angle Surface Mount	Differential Pair Array MALE	0.246 in	10 Ąin	Board Guide Mounting Flange	2	50
Samtec Inc. ERM8-025-01-S-D-EM2-DS-TR	0.031 in	Gold	Board Edge Straddle Mount	Differential Pair Array MALE		30 µin		2	50
Samtec Inc. ERM8-025-05.0-L-DV-DS-K-TR	0.031 in	Gold	Surface Mount	Differential Pair Array MALE	0.351 in	10 Ąin	Board Guide Pick and Place	2	50	10mm 12mm 15mm
