LS102MASE7EHA
ObsoleteNXP USA Inc.
IC MPU QORLQ LS1 650MHZ 448PBGA
LS102MASE7EHA
ObsoleteNXP USA Inc.
IC MPU QORLQ LS1 650MHZ 448PBGA
Description
General part information
LS102 Series
ARM1136JF-S Microprocessor IC QorlQ LS1 2 Core, 32-Bit 650MHz 448-PBGA w/Heat Spreader (23x23)
Technical Specifications
Parameters and characteristics for this part
| Specification | LS102MASE7EHA |
|---|---|
| Additional Interfaces | SPI, UART, I2C, TDM, PCM, PCIe |
| Bus Width | 32 Bit |
| Core Processor | ARM1136JF-S |
| Ethernet Interface | GbE |
| Ethernet Ports | 2 |
| Graphics Acceleration | No |
| Mounting Type | Surface Mount |
| Number of Cores | 2 Core |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Package / Case | 448-FBGA Exposed Pad |
| Package Length | 23 mm |
| Package Name | 448-PBGA w/Heat Spreader |
| Package Width | 23 mm |
| RAM Controllers | DDR2 |
| Speed | 650 MHz |
| USB | USB 2.0 + PHY |
| USB 2.0 PHY Count | 1 count |
