PKE5225PI

Active

Flex Power Modules

DC DC CONVERTER +/-15V 15W

Search across all available documentation for this part.

Active

Flex Power Modules

DC DC CONVERTER +/-15V 15W

Technical Specifications

Parameters and characteristics for this part

Specification	PKE5225PI

Applications	ITE (Commercial)
Approval Agency	CB, UL, IEC, TUV, CSA
Control Features	Active Low, Enable
Current - Output (Max)	500 mA
Current - Output (Max)	500 mA
Efficiency	89 %
Features	Remote On/Off, Adjustable Output
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature [Max]	115 °C
Operating Temperature [Min]	-40 °C
Package / Case	6-DIP Module
Power (Watts)	15 W
Size / Dimension [x]	25.4 mm
Size / Dimension [x]	1 in
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	0.43 "
Size / Dimension [z]	10.8 mm
Standard Number	62368-1
Type	Isolated Module
Voltage - Input (Max) [Max]	75 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	15 V
Voltage - Output 2	-15 V

Part	Voltage - Isolation	Type	Number of Outputs	Mounting Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Package / Case	Control Features	Voltage - Input (Max) [Max]	Standard Number	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 2	Applications	Approval Agency	Current - Output (Max)	Current - Output (Max)	Features	Current - Output (Max)
Flex Power Modules PKE5221PI	1.5 kV	Isolated Module	2	Through Hole	25.4 mm	1 in	25.4 mm	0.43 "	10.8 mm	25.4 mm	89 %	6-DIP Module	Active Low Enable	75 V	62368-1	18 V	15 W	12 V	-40 °C	115 °C	-12 V	ITE (Commercial)	CB CSA IEC TUV UL	625 mA	625 mA	Adjustable Output Remote On/Off
Flex Power Modules PKE5225PI	1.5 kV	Isolated Module	2	Through Hole	25.4 mm	1 in	25.4 mm	0.43 "	10.8 mm	25.4 mm	89 %	6-DIP Module	Active Low Enable	75 V	62368-1	18 V	15 W	15 V	-40 °C	115 °C	-15 V	ITE (Commercial)	CB CSA IEC TUV UL		500 mA	Adjustable Output Remote On/Off	500 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	250	$ 22.61

General part information

Isolated Module DC DC Converter 2 Output 15V -15V 500mA, 500mA 18V - 75V Input

Technical documentation and resources
