| Adapter Series | - | SMA to FME, SMA to SMA |
| Adapter Type | - | Plug to Plug, Jack to Jack |
| Approval Agency | - | EAC, UL, EAC, UL, BV, DNV, ATEX, CCC, PRS, IECEx, UKEX, CE |
| Center Gender | - | Male to Male, Female to Female |
| Coil Current | 13.8 mA | 1.7 - 75 mA |
| Coil Resistance | 1.74 kOhms | 1.14 - 11000 kOhms |
| Coil Type | Non Latching | Non Latching |
| Coil Voltage | 24 VDC | 5 - 240 VDC |
| Coil Voltage | - | 24 VAC |
| Coil Voltage | - | 230 VAC |
| Contact Form | DPST-NO/NC | SPST-NO (1 Form A), SPDT (1 Form C), DPST-NO/NC, SPST-NC (1 Form B), 4PDT (4 Form C), DPDT (2 Form C), DPST-NO (2 Form A), 4PST-1NO/3NC (1 Form A, 3 Form B), 4PST-2NO/2NC (2 Form A, 2 Form B), 4PST-NO (4 Form A) |
| Contact Material | Silver Nickel (AgNi) | Silver Tin Oxide (AgSnO), Silver Nickel (AgNi), Silver Cerium (AgCe), Gold (Au) |
| Contact Rating (Current) | 8 A | 3 - 16 A |
| Contact Rating @ Voltage | - | 1 - 250 A |
| Conversion Type | - | Between Series, Same Series |
| Convert From (Adapter End) | - | SMA Plug, Male Pin, Female Socket, SMA Jack |
| Convert To (Adapter End) | - | Male Pin, FME Plug, SMA Plug, FME Jack, Female Socket |
| Delay Time | - | 100 - 300 Hrs |
| Delay Time | - | 0.01 - 0.1 Sec |
| Display Type | - | LCD - Blue Characters, Backlight |
| Features | Lighted Indicator | Lighted Indicator |
| Function | - | Programmable (Multi-Function) |
| Ingress Protection | - | IP51 - Dust Protected |
| Load - Max Switching | 2000 VA | 750 - 6400 VA |
| Load - Max Switching | - | 1250 - 3000 VA |
| Load Current | - | 1 - 100 A |
| Measuring Range | - | 0 - 230 Hz |
| Measuring Range | - | 65 - 400 VAC |
| Measuring Type | - | Current (3-Phase), Wattage, Voltage |
| Mounting Type | Socketable | DIN Rail, Socketable, Through Hole, Free Hanging (In-Line) |
| Operate Time | 8 ms | 6 - 25 ms |
| Operating Temperature | - | -40 - -20 °C |
| Operating Temperature | - | 40 - 85 °C |
| Output Type | - | AC, Zero Cross, DC |
| Package / Case | - | Module, 4-SIP |
| Pin or Socket | - | Non-Gendered |
| Relay Type | General Purpose | General Purpose, Mechanical Relay, Solid State Relay |
| Release Time | 6 ms | 2 - 35 ms |
| Style | - | Straight |
| Supplier Device Package | - | 4-SIP |
| Switching Voltage | 250 VAC | 250 VAC |
| Switching Voltage | - | 400 VAC |
| Termination Style | Plug In | Spring Terminal, Plug In, Screw Terminal, PC Pin |
| Timing Adjustment Method | - | Screwdriver Slot |
| Timing Initiate Method | - | Input Voltage |
| Type | - | Energy Monitor |
| Voltage - Input | - | 24VAC/DC |
| Voltage - Input | - | 5 - 230 V |
| Voltage - Input | - | 30 - 120 V |
| Voltage - Input | - | 15 - 100 V |
| Voltage - Load | - | 30 - 275 V |
| Voltage - Load | - | 0 - 24 V |
| Voltage - Supply | - | 24 - 230 VDC |
