MAX2181AETE/V+T

MAX2181AETE/V+T

Active
Analog Devices Inc./Maxim Integrated

FM AUTOMOTIVE LOW-NOISE AMPLIFIER

Find alt
MAX2181AETE/V+T

MAX2181AETE/V+T

Active
Analog Devices Inc./Maxim Integrated

FM AUTOMOTIVE LOW-NOISE AMPLIFIER

Find alt

Description

General part information

MAX2181 Series

The MAX2181A is a highly integrated FM variable-gain low-noise amplifier ideal for use in automotive FM and FM-diversity active antenna applications. The device features an FM signal path, providing 30dB of gain range, controlled by an on-chip power detector. The FM signal path covers 76MHz to 162.5MHz.The device is available in a small, 3mm x 3mm, TQFN package and operates over the extended industrial temperature range (-40°C to +85°C).ApplicationsAutomotive Active AntennaAutomotive Head Unit

Technical Specifications

Parameters and characteristics for this part

SpecificationMAX2181AETE/V+T
Current - Supply56 mA
Frequency (Max)162.5 MHz
Frequency (Min)76 MHz
Gain8.5 dB
Mounting TypeSurface Mount
Noise Figure2.7 dB
Package / Case16-WFQFN Exposed Pad
Package Length3 mm
Package Name16-TQFN
Package Width3 mm
Voltage - Supply5 VDC
