PT580048

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 4PDT 6A 48V

Search across all available documentation for this part.

Active

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE 4PDT 6A 48V

Technical Specifications

Parameters and characteristics for this part

Part	Coil Type	Release Time	Load - Max Switching	Relay Type	Coil Resistance	Approval Agency	Coil Voltage	Operate Time	Operating Temperature [Min]	Operating Temperature [Max]	Must Release Voltage	Contact Rating (Current)	Must Operate Voltage	Coil Insulation	Mounting Type	Switching Voltage	Contact Form	Coil Current	Contact Material	Load - Max Switching [Max]	Switching Voltage [Max]	Features
TE Connectivity Potter & Brumfield Relays PT580024	Non Latching	10 ms	1440 VA	General Purpose	777 Ohms	cURus VDE	24 VDC	15 ms	-40 °C	70 °C	2.4 VDC	6 A	18 VDC	Class F	Socketable	240 VAC	4PDT (4 Form C)	30.8 mA	Silver Nickel (AgNi)
TE Connectivity Potter & Brumfield Relays PT580012	Non Latching	10 ms		General Purpose	192 Ohms	cURus VDE	12 VDC	15 ms	-40 °C	70 °C	1.2 VDC	6 A	9 VDC	Class F	Socketable		4PDT (4 Form C)	62.5 mA	Gold (Au) Silver Nickel (AgNi)	2400 VA	400 VAC
TE Connectivity Potter & Brumfield Relays PT580048	Non Latching	10 ms		General Purpose	3.072 kOhms	cURus VDE	48 VDC	15 ms	-40 °C	70 °C	4.8 VDC	6 A	36 VDC	Class F	Socketable		4PDT (4 Form C)	15.6 mA	Gold (Au) Silver Nickel (AgNi)	2400 VA	400 VAC
TE Connectivity Potter & Brumfield Relays 6-1415026-1	Non Latching	10 ms	1440 VA	General Purpose	192 Ohms	cURus VDE	24 VAC	15 ms	-40 °C	70 °C	7.2 VAC	6 A	21.6 VAC	Class F	Socketable	240 VAC	4PDT (4 Form C)	125 mA	Silver Nickel (AgNi)			Lighted Indicator Test Button

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 21.45

General part information

General Purpose Relay 4PDT (4 Form C) 48VDC Coil Socketable
