PSK-S15C-3-DIN

Obsolete

CUI Inc.

AC/DC DIN RAIL SUPPLY 3.3V 8.9W

Deep-Dive with AI

Search across all available documentation for this part.

PSK-S15C-3-DIN

Obsolete

CUI Inc.

AC/DC DIN RAIL SUPPLY 3.3V 8.9W

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PSK-S15C-3-DIN

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Approval Agency	EN, CB Scheme, UL, IEC
Current - Output (Max) [Max]	2.7 A
DC Voltage - Input (Max) [Max]	370 V
DC Voltage - Input (Min) [Min]	100 V
Efficiency	72 %
Features	Universal Input
Input Type	AC or DC
Number of Outputs	1
Power (Watts)	8.9 W
Size / Dimension [x]	36.9 mm
Size / Dimension [x]	1.45 "
Size / Dimension [y]	1.24 in
Size / Dimension [y]	31.5 mm
Size / Dimension [z]	2.99 in
Size / Dimension [z]	76 mm
Standard Number	55024, 62368-1, 55032 Class A, 60950-1, 61000-3-2
Voltage - Isolation	4000 V
Voltage - Output 1	3.3 V

PSK-S15 Series

Part	Number of Outputs	Current - Output 1	Voltage - Input [Max]	Voltage - Input [Min]	Type	Standard Number	Power (Watts)	Applications	Voltage - Output 1	Efficiency	Voltage - Isolation	Features	Approval Agency	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	DC Voltage - Input (Max) [Max]	AC Voltage - Input [Min]	AC Voltage - Input [Max]	DC Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Input Type	Load Regulation	Line Regulation	Package / Case
CUI Inc. PSK-S15C-3-T	1	2.7 A	264 VAC 370 VDC	85 VAC 100 V	Enclosed	55024 55032 Class A 60950-1 61000-3-2 62368-1	8.9 W	ITE (Commercial)	3.3 V	72 %	4000 V	Universal Input	CB Scheme EN IEC UL	Chassis Mount
CUI Inc. PSK-S15C-12-DIN	1					55024 55032 Class A 60950-1 61000-3-2 62368-1	15 W	ITE (Commercial)	12 V	80 %	4000 V	Universal Input	CB Scheme EN IEC UL		1.24 in	36.9 mm	1.45 "	31.5 mm	2.99 in	76 mm	370 V	85 VAC	264 VAC	100 V	1.25 A	AC or DC
CUI Inc. PSK-S15C-15-T	1	1 A	264 VAC 370 VDC	85 VAC 100 V	Enclosed	55024 55032 Class A 60950-1 61000-3-2 62368-1	15 W	ITE (Commercial)	15 V	81 %	4000 V	Universal Input	CB Scheme EN IEC UL	Chassis Mount
CUI Inc. PSK-S15C-3-DIN	1					55024 55032 Class A 60950-1 61000-3-2 62368-1	8.9 W	ITE (Commercial)	3.3 V	72 %	4000 V	Universal Input	CB Scheme EN IEC UL		1.24 in	36.9 mm	1.45 "	31.5 mm	2.99 in	76 mm	370 V	85 VAC	264 VAC	100 V	2.7 A	AC or DC
CUI Inc. PSK-S15C-24	1		264 VAC 370 VDC	85 VAC 100 V	Enclosed	55024 55032 Class A 60950-1 61000-3-2 62368-1	15 W	ITE (Commercial)	24 V	81 %		Universal Input	CB Scheme EN IEC UL	Through Hole	1.13 in	53.8 mm	2.12 "	28.8 mm	0.93 in	23.5 mm					625 mA		1 %	0.5 %	4-DIP Module
CUI Inc. PSK-S15C-24-DIN	1					55024 55032 Class A 60950-1 61000-3-2 62368-1	15 W	ITE (Commercial)	24 V	81 %	4000 V	Universal Input	CB Scheme EN IEC UL		1.24 in	36.9 mm	1.45 "	31.5 mm	2.99 in	76 mm	370 V	85 VAC	264 VAC	100 V	625 mA	AC or DC
CUI Inc. PSK-S15C-15	1		264 VAC 370 VDC	85 VAC 100 V	Enclosed	55024 55032 Class A 60950-1 61000-3-2 62368-1	15 W	ITE (Commercial)	15 V	81 %		Universal Input	CB Scheme EN IEC UL	Through Hole	1.13 in	53.8 mm	2.12 "	28.8 mm	0.93 in	23.5 mm					1 A		1 %	0.5 %	4-DIP Module

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

PSK-S15 Series

AC/DC DIN RAIL SUPPLY 3.3V 8.9W

Documents

Technical documentation and resources

No documents available
