FN7563-200-M10
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 4.7UF 650V AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FN7563-200-M10
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 4.7UF 650V AXIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN7563-200-M10 |
|---|---|
| Capacitance | 4.7 µF |
| Current | 200 A |
| DC Resistance (DCR) (Max) | 0.14 mOhm |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Axial - Threaded Terminals |
| Ratings | Y4 |
| Size / Dimension [diameter] | 2.126 in |
| Size / Dimension [diameter] | 54 mm |
| Size / Dimension [x] | 6.496 in |
| Size / Dimension [x] | 165 mm |
| Thread Size | M27x1.5 |
| Tolerance | 20 % |
| Voltage - Rated | 650 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 176.94 | |
| 10 | $ 145.17 | |||
| 40 | $ 133.70 | |||
Description
General part information
FN7563 Series
4.7 µF Feed Through Capacitor 650V 200 A 0.14mOhm (Typ) Axial - Threaded Terminals
