M80-7820422

Active

Harwin Inc.

4 POS. MALE SIL VERTICAL THROUGHBOARD CONN. LATCHES ROHS COMPLIANT: NO

Search across all available documentation for this part.

Active

Harwin Inc.

4 POS. MALE SIL VERTICAL THROUGHBOARD CONN. LATCHES ROHS COMPLIANT: NO

Technical Specifications

Parameters and characteristics for this part

Specification	M80-7820422

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Tin-Lead
Contact Finish Thickness - Mating	29.5 Áin
Contact Finish Thickness - Mating	0.75 Ám
Contact Finish Thickness - Post	3 µm
Contact Finish Thickness - Post	118.1 µin
Contact Length - Post	0.177 in
Contact Length - Post	4.5 mm
Contact Material	Phosphor Bronze
Contact Shape	Circular
Contact Type	Male Pin
Current Rating (Amps)	2.2 A
Fastening Type	Latch Lock
Insulation Color	Black
Insulation Height	5.56 mm
Insulation Height [z]	0.219 in
Insulation Material	Polyphenylene Sulfide (PPS), Glass Filled
Mated Stacking Heights	13.46 mm, 7.23 mm, 10.2 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	4
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Shrouding	Shrouded - 4 Wall
Style	Board to Board, Cable
Termination	Solder
Voltage Rating	120 VDC

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Color	Insulation Material	Contact Type	Pitch - Mating [x]	Pitch - Mating [x]	Contact Length - Post	Contact Length - Post	Fastening Type	Contact Shape	Mounting Type	Insulation Height [z]	Insulation Height	Mated Stacking Heights	Termination	Voltage Rating	Connector Type	Number of Rows	Shrouding	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Current Rating (Amps)	Contact Material	Style	Number of Positions	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Post	Material Flammability Rating
Harwin Inc. M80-7820222	3 µm	118.1 µin	Black	Polyphenylene Sulfide (PPS) Glass Filled	Male Pin	0.079 in	2 mm	0.177 in	4.5 mm	Latch Lock	Circular	Through Hole	0.219 in	5.56 mm	7.23 mm 10.2 mm 13.46 mm	Solder	120 VDC	Header	1	Shrouded - 4 Wall	-55 °C	125 °C	Gold	2.2 A	Phosphor Bronze	Board to Board Cable	2	All	29.5 Áin	0.75 Ám	Tin-Lead	UL94 V-0
Harwin Inc. M80-7820422	3 µm	118.1 µin	Black	Polyphenylene Sulfide (PPS) Glass Filled	Male Pin	0.079 in	2 mm	0.177 in	4.5 mm	Latch Lock	Circular	Through Hole	0.219 in	5.56 mm	7.23 mm 10.2 mm 13.46 mm	Solder	120 VDC	Header	1	Shrouded - 4 Wall	-55 °C	125 °C	Gold	2.2 A	Phosphor Bronze	Board to Board Cable	4	All	29.5 Áin	0.75 Ám	Tin-Lead	UL94 V-0

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1008	$ 1.74
Newark	Each	1000	$ 2.01
		2500	$ 1.82

General part information

Connector Header Through Hole 4 position 0.079" (2.00mm)
