MAX14775EEVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD MAX14775E MAX14776E
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX14775EEVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD MAX14775E MAX14776E
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX14775EEVKIT# | MAX14775 Series |
|---|---|---|
| Contents | Board(s) | Board(s) |
| Data Rate | - | 20 Mbps |
| Duplex | - | Half |
| Function | RS-422, RS-485, Transceiver | RS-422, RS-485, Transceiver |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 125 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 8-WDFN Exposed Pad, 8-SOIC |
| Package / Case | - | 3.9 mm |
| Protocol | - | RS422, RS485 |
| Receiver Hysteresis | - | 250 mV |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 8-TDFN (3x3), 8-SOIC |
| Type | Interface | Interface, Transceiver |
| Utilized IC / Part | MAX14776E, MAX14775E | MAX14776E, MAX14775E |
| Voltage - Supply | - | 3 V |
| Voltage - Supply | - | 5.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
MAX14775 Series
EVAL BOARD MAX14775E MAX14776E
| Part | Utilized IC / Part | Type | Contents | Supplied Contents | Function | Duplex | Package / Case | Supplier Device Package | Data Rate | Receiver Hysteresis | Protocol | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Min] | Voltage - Supply [Max] | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX14775EEVKIT#MAX14775E, MAX14776E Transceiver, RS-422, RS-485 Interface Evaluation Board | MAX14775E, MAX14776E | Interface | Board(s) | Board(s) | RS-422, RS-485, Transceiver | ||||||||||||
Transceiver | Half | 8-WDFN Exposed Pad | 8-TDFN (3x3) | 20 Mbps | 250 mV | RS422, RS485 | 125 °C | -40 °C | 3 V | 5.5 V | Surface Mount | ||||||
Transceiver | Half | 8-WDFN Exposed Pad | 8-TDFN (3x3) | 20 Mbps | 250 mV | RS422, RS485 | 125 °C | -40 °C | 3 V | 5.5 V | Surface Mount | ||||||
Transceiver | Half | 8-SOIC | 8-SOIC | 20 Mbps | 250 mV | RS422, RS485 | 125 °C | -40 °C | 3 V | 5.5 V | Surface Mount | 3.9 mm | |||||
Transceiver | Half | 8-SOIC | 8-SOIC | 20 Mbps | 250 mV | RS422, RS485 | 125 °C | -40 °C | 3 V | 5.5 V | Surface Mount | 3.9 mm |
Description
General part information
MAX14775 Series
MAX14775E, MAX14776E Transceiver, RS-422, RS-485 Interface Evaluation Board
