Technical Specifications
Parameters and characteristics for this part
| Specification | SG73P2ARTTD1620F |
|---|---|
| Composition | Thick Film |
| Features | Anti-Sulfur, Pulse Withstanding, Automotive AEC-Q200 |
| Height - Seated (Max) | 0.024 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 0805 (2012 Metric) |
| Package Name | 0805 |
| Power (Watts) | 500 mW |
| Power (Watts) Options | 1/2W |
| Ratings | AEC-Q200 |
| Resistance | 162 Ohm |
| Size / Dimension Length | 0.079 in |
| Size / Dimension Width | 0.049 in |
| Temperature Coefficient | 200 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | Updated |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 5000 | $ 0.03 | <6d |
CAD
3D models and CAD resources for this part
Description
General part information
SG73P2A Series
162 Ohms ±1% 0.5W, 1/2W Chip Resistor 0805 (2012 Metric) Anti-Sulfur, Automotive AEC-Q200, Pulse Withstanding Thick Film
