TUHS25F24

Active

Cosel USA, Inc.

AC/DC CONVERTER 24V 25W

Search across all available documentation for this part.

Active

Cosel USA, Inc.

AC/DC CONVERTER 24V 25W

Technical Specifications

Parameters and characteristics for this part

Part	Applications	Current - Output (Max) [Max]	Voltage - Input [Min]	Voltage - Input [Max]	Features	Load Regulation	Voltage - Output 1	Number of Outputs	Power (Watts)	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Line Regulation	Type	Efficiency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Mounting Type
Cosel USA, Inc. TUHS25F05	ITE (Commercial)	5 A	85 VAC 120 VDC	264 VAC 370 VDC	Universal Input	40 mV	5 V	1	25 W	6-DIP Module	85 °C	-40 °C	CE cURus	20 mV	Enclosed	87 %	25.4 mm	1.42 in	36.1 mm	0.65 in	16.5 mm	25.4 mm	Through Hole
Cosel USA, Inc. TUHS25F24	ITE (Commercial)		85 VAC 120 VDC	264 VAC 370 VDC	Universal Input	150 mV	24 V	1	25 W	6-DIP Module	85 °C	-40 °C	CE cURus	96 mV	Enclosed	90 %	25.4 mm	1.42 in	36.1 mm	0.65 in	16.5 mm	25.4 mm	Through Hole
Cosel USA, Inc. TUHS25F12	ITE (Commercial)	2.1 A	85 VAC 120 VDC	264 VAC 370 VDC	Universal Input	100 mV	12 V	1	25 W	6-DIP Module	85 °C	-40 °C	CE cURus	48 mV	Enclosed	88 %	25.4 mm	1.42 in	36.1 mm	0.65 in	16.5 mm	25.4 mm	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 24V 1.1A 85 ~ 264 VAC, 120 ~ 370 VDC Input
