Specification	9250A-276-RC

Current - Saturation (Isat)	0.008 mA
Current Rating	16 mA
DC Resistance (DCR) (Max)	308 Ohm
Frequency - Self Resonant	210 kHz
Inductance	27 mH
Inductance Frequency - Test	79 kHz
Material - Core	Ferrite
Mounting Type	Through Hole
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	Axial
Q	27
Shielding	Shielded
Size / Dimension Diameter	0.162 in
Size / Dimension Length	0.41 in
Tolerance	10 %
Type	Molded

9250A Series

Part	Inductance	Shielding	Package / Case	DC Resistance (DCR) (Max)	Type	Frequency - Self Resonant	Size / Dimension Length	Size / Dimension Diameter	Operating Temperature (Max)	Operating Temperature (Min)	Current - Saturation (Isat)	Q	Tolerance	Material - Core	Inductance Frequency - Test	Current Rating	Mounting Type
Bourns Inc. 9250A-152-RC	1.5 µH	Shielded	Axial	120 mOhm	Molded	115 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.815 mA	44	10 %	Ferrite	7.9 MHz	815 mA	Through Hole
Bourns Inc. 9250A-124-RC	120 µH	Shielded	Axial	3.6 Ohm	Molded	9.7 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.095 mA	55	10 %	Ferrite	790 kHz	150 mA	Through Hole
Bourns Inc. 9250A-334-RC	330 µH	Shielded	Axial	6.4 Ohm	Molded	6.5 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.065 mA	55	10 %	Ferrite	790 kHz	110 mA	Through Hole
Bourns Inc. 9250A-223-RC	22 µH	Shielded	Axial	960 mOhm	Molded	41 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.22 mA	45	10 %	Ferrite	2.5 MHz	0.29 A	Through Hole
Bourns Inc. 9250A-101-RC	100 nH	Shielded	Axial	25 mOhm	Molded	250 MHz	0.41 in	0.162 in	125 °C	-55 °C	1.79 A	50	10 %	Ferrite	25 MHz	1.79 A	Through Hole
Bourns Inc. 9250A-155-RC	1.5 mH	Shielded	Axial	26.5 Ohm	Molded	1.2 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.033 mA	45	10 %	Ferrite	250 kHz	0.055 A	Through Hole
Bourns Inc. 9250A-184-RC	180 µH	Shielded	Axial	4.4 Ohm	Molded	8 MHz	0.41 in	0.162 in	125 °C	-55 °C	85 mA	55	10 %	Ferrite	790 kHz	135 mA	Through Hole
Bourns Inc. 9250A-683-RC	68 µH	Shielded	Axial	2.7 Ohm	Molded	21 MHz	0.41 in	0.162 in	125 °C	-55 °C	150 mA	50	10 %	Ferrite	2.5 MHz	0.17 A	Through Hole
Bourns Inc. 9250A-122-RC	1.2 µH	Shielded	Axial	100 mOhm	Molded	130 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.895 mA	44	10 %	Ferrite	7.9 MHz	895 mA	Through Hole
Bourns Inc. 9250A-182-RC	1.8 µH	Shielded	Axial	140 mOhm	Molded	105 MHz	0.41 in	0.162 in	125 °C	-55 °C	0.775 mA	44	10 %	Ferrite	7.9 MHz	775 mA	Through Hole

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

9250A-276-RC | Datasheet
