AB-FD01265-19712-8A1

Active

American Bright Optoelectronics Corporation

LED MOD AB-FD WH LNR STRP 6500K

Search across all available documentation for this part.

Active

American Bright Optoelectronics Corporation

LED MOD AB-FD WH LNR STRP 6500K

Technical Specifications

Parameters and characteristics for this part

Specification	AB-FD01265-19712-8A1

CCT (K)	6500 K
Color	Cool, White
Configuration	Linear Light Strip, Flexible
CRI (Color Rendering Index)	80
Current - Test	660 mA
Features	IP68
Height [z]	6.5 mm
Lens Type	Flat
Lumens/Watt @ Current - Test	91 lm/W
Luminous Flux @ Current/Temperature	720 lm
Size / Dimension [x]	5000 mm
Size / Dimension [y]	12.5 mm
Type	LED Module
Viewing Angle	120 °
Voltage - Forward (Vf) (Typ)	12 V

LED MOD AB-FD WH LNR STRP 6500K

Part	Features	Color	CCT (K)	Viewing Angle	Luminous Flux @ Current/Temperature	Lumens/Watt @ Current - Test	Lens Type	Height [z]	Configuration	Size / Dimension [x]	Size / Dimension [y]	Current - Test	Type	Voltage - Forward (Vf) (Typ)	CRI (Color Rendering Index)
American Bright Optoelectronics Corporation AB-FD01265-19712-8A1	IP68	Cool, White	6500 K	120 °	720 lm	91 lm/W	Flat	6.5 mm	Flexible, Linear Light Strip	5000 mm	12.5 mm	660 mA	LED Module	12 V	80

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	20	$ 59.88

General part information

LED Lighting COBs Engines Modules LED Module AB-FD White, Cool Linear Light Strip, Flexible
