Specification	46.52.9.012.0040

Approval Agency	cURus, CE, ENEC, RINA, UKCA, CCC, VDE, CSA, EAC
Coil Current	40 mA
Coil Resistance	300 Ohms
Coil Type	Non Latching
Coil Voltage	12 VAC
Contact Form	Form, 2 Form C, C, 2, DPDT
Contact Material	Silver Nickel (AgNi)
Contact Rating (Current)	8 A
Features	Test Button, Mechanical Indicator
Load - Max Switching (Apparent Power)	3520 VA
Mounting Type	Socketable
Must Operate Voltage	8.8 VDC
Must Release Voltage	2.4 V
Operate Time	10 ms
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-40 °C
Quick Connect Size (0.110")	0.11 in
Relay Type	General Purpose
Release Time	3 ms
Switching Voltage AC (Max)	440 VAC
Termination Style	Quick Connect, Plug In

46.52.9 Series

Part	Coil Current	Contact Material	Must Operate Voltage	Operate Time	Switching Voltage AC (Max)	Must Release Voltage	Coil Type	Features	Mounting Type	Relay Type	Operating Temperature (Min)	Operating Temperature (Max)	Contact Form	Load - Max Switching (Apparent Power)	Coil Voltage	Contact Rating (Current)	Release Time	Approval Agency	Quick Connect Size (0.110")	Termination Style	Coil Resistance
Finder Relays, Inc. 46.52.9.125.0040	3.9 mA	Silver Nickel (AgNi)	91.2 VDC	10 ms	440 VAC	25 VAC	Non Latching	Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	125 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	32 kOhms
Finder Relays, Inc. 46.52.9.024.5040	0.02 A	Gold (Au) Silver Nickel (AgNi)	17.5 VDC	10 ms	440 VAC	4.8 VAC	Non Latching	Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	24 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	1.2 kOhms
Finder Relays, Inc. 46.52.9.024.0020	0.02 A	Silver Nickel (AgNi)	17.5 VDC	10 ms	440 VAC	4.8 VAC	Non Latching	Mechanical Indicator	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	24 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	1.2 kOhms
Finder Relays, Inc. 46.52.9.024.5000T	0.02 A	Gold (Au) Silver Nickel (AgNi)	17.5 VDC	10 ms	440 VAC	4.8 VAC	Non Latching		Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	24 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	1.2 kOhms
Finder Relays, Inc. 46.52.9.125.0074	3.9 mA	Silver Nickel (AgNi)	91.2 VDC	10 ms	440 VAC	25 VAC	Non Latching	Lighted Indicator Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	125 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	32 kOhms
Finder Relays, Inc. 46.52.9.048.0074	10 mA	Silver Nickel (AgNi)	35 VDC	10 ms	440 VAC	9.6 VDC	Non Latching	Lighted Indicator Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	48 V	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	4.8 kOhms
Finder Relays, Inc. 46.52.9.012.0040	40 mA	Silver Nickel (AgNi)	8.8 VDC	10 ms	440 VAC	2.4 V	Non Latching	Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	12 VAC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	300 Ohms
Finder Relays, Inc. 46.52.9.024.0074	0.02 A	Silver Nickel (AgNi)	17.5 VDC	10 ms	440 VAC	4.8 VAC	Non Latching	Lighted Indicator Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	24 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	1.2 kOhms
Finder Relays, Inc. 46.52.9.110.0040	4.7 mA	Silver Nickel (AgNi)	80 VDC	10 ms	440 VAC	22 VDC	Non Latching	Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	110 V	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	23.5 kOhms
Finder Relays, Inc. 46.52.9.024.5074	0.02 A	Gold (Au) Silver Nickel (AgNi)	17.5 VDC	10 ms	440 VAC	4.8 VAC	Non Latching	Lighted Indicator Mechanical Indicator Test Button	Socketable	General Purpose	-40 °C	70 °C	2 2 Form C C DPDT Form	3520 VA	24 VDC	8 A	3 ms	CCC CE CSA cURus EAC ENEC RINA UKCA VDE	0.11 in	Plug In Quick Connect	1.2 kOhms

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

46.52.9.012.0040 | Datasheet
