LIM301
ActiveL3 Narda-MITEQ
IC RF SWITCH 18GHZ MODULE
LIM301
ActiveL3 Narda-MITEQ
IC RF SWITCH 18GHZ MODULE
Description
General part information
LIM301 Series
RF Switch IC General Purpose Module
Technical Specifications
Parameters and characteristics for this part
| Specification | LIM301 |
|---|---|
| Frequency Range (Max) | 18 GHz |
| Frequency Range (Min) | 2 GHz |
| Insertion Loss (max) | 2.7 dB |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -30 °C |
| P1dB (Min) | 50 dBm |
| Package / Case | Module, SMA Connectors |
| Package Name | Module |
| RF Type | General Purpose |
| Test Frequency | 18 GHz |
