MMT-124-02-S-SH-P

Active

Samtec Inc.

CONN HEADER SMD R/A 24POS 2MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

MMT-124-02-S-SH-P

Active

Samtec Inc.

CONN HEADER SMD R/A 24POS 2MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	MMT-124-02-S-SH-P

null

MMT-124 Series

Part	Number of Positions Loaded	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Rows	Style	Shrouding	Contact Length - Mating	Contact Length - Mating	Row Spacing - Mating	Row Spacing - Mating	Insulation Height [custom]	Insulation Height [custom]	Number of Positions	Mounting Type	Contact Finish - Post	Fastening Type	Contact Material	Insulation Color	Termination	Connector Type	Current Rating (Amps)	Contact Type	Pitch - Mating [x]	Pitch - Mating [x]	Insulation Material	Material Flammability Rating	Contact Finish - Mating	Features	Insulation Height	Insulation Height
Samtec Inc. MMT-124-01-S-MT	All	Square	-55 °C	125 °C	30 Áin	0.76 Ám	2	Board to Board Cable	Unshrouded	3.2 mm	0.126 "	0.079 in	2 mm	0.157 in	4 mm	48	Surface Mount Right Angle Through Hole	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold
Samtec Inc. MMT-124-01-S-SH		Square	-55 °C	125 °C			1	Board to Board Cable	Unshrouded							24	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header		Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold
Samtec Inc. MMT-124-01-S-DH-P	All	Square	-55 °C	125 °C	30 Áin	0.76 Ám	2	Board to Board Cable	Unshrouded	3.2 mm	0.126 "	0.079 in	2 mm	0.157 in	4 mm	48	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold	Pick and Place
Samtec Inc. MMT-124-01-F-DH	All	Square	-55 °C	125 °C	3 µin	0.076 µm	2	Board to Board Cable	Unshrouded	3.2 mm	0.126 "	0.079 in	2 mm	0.157 in	4 mm	48	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold
Samtec Inc. MMT-124-02-S-SH-A	All	Square	-55 °C	125 °C	30 Áin	0.76 Ám	1	Board to Board Cable	Unshrouded	4.45 mm	0.175 in					24	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold	Board Guide	0.079 in	2 mm
Samtec Inc. MMT-124-01-T-DH-P	All	Square	-55 °C	105 ░C			2	Board to Board Cable	Unshrouded	3.2 mm	0.126 "	0.079 in	2 mm	0.157 in	4 mm	48	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0		Pick and Place
Samtec Inc. MMT-124-01-F-DH-TR	All	Square	-55 °C	125 °C	3 µin	0.076 µm	2	Board to Board Cable	Unshrouded	3.2 mm	0.126 "	0.079 in	2 mm	0.157 in	4 mm	48	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold
Samtec Inc. MMT-124-01-T-SH	All	Square	-55 °C	105 ░C			1	Board to Board Cable	Unshrouded	3.2 mm	0.126 "					24	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0			0.079 in	2 mm
Samtec Inc. MMT-124-02-S-SH-P
Samtec Inc. MMT-124-01-F-DH-A-P-TR	All	Square	-55 °C	125 °C	3 µin	0.076 µm	2	Board to Board Cable	Unshrouded	3.2 mm	0.126 "	0.079 in	2 mm	0.157 in	4 mm	48	Surface Mount Right Angle	Tin	Push-Pull	Phosphor Bronze	Black	Solder	Header	3 A	Male Pin	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	UL94 V-0	Gold	Board Guide Pick and Place
