4-1415011-1
ObsoleteTE Connectivity Potter & Brumfield Relays
RELAY GEN PURPOSE DPDT 10A 125V
Deep-Dive with AI
Search across all available documentation for this part.
4-1415011-1
ObsoleteTE Connectivity Potter & Brumfield Relays
RELAY GEN PURPOSE DPDT 10A 125V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 4-1415011-1 |
|---|---|
| Approval Agency | cURus, VDE |
| Coil Insulation | Class B |
| Coil Type | Non Latching |
| Coil Voltage | 125 VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 10 A |
| Features | Test Button |
| Load - Max Switching [Max] | 2500 VA |
| Mounting Type | Socketable |
| Must Operate Voltage | 93.75 VDC |
| Must Release Voltage | 12.5 VDC |
| Operate Time | 15 ms |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 10 ms |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | Plug In, 8 Pin (Octal) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
MT2211 Series
General Purpose Relay DPDT (2 Form C) 125VDC Coil Socketable
