BPT-125MM

Active

Bertech

TAPE MASKING BLUE 4.92"X72YDS

Search across all available documentation for this part.

Active

Bertech

TAPE MASKING BLUE 4.92"X72YDS

Technical Specifications

Parameters and characteristics for this part

TAPE MASKING BLUE 4.92"X72YDS

Part	Width [y]	Width [y]	Usage	Color	Tape Type	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive [x]	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Max]	Temperature Range [Min]	Thickness	Thickness	Thickness	Length	Length	Length	Backing, Carrier	Adhesive
Bertech BPT-125MM	125 mm	4.92 in	Masking	Blue	Masking	2 mils	0.051 mm	0.002 "	1 mils	0.025 mm	0.001 "	-99 °F	204 °C	399 °F	-73 °C	3 mils	0.003 in	0.076 mm	66 m	216 ft	72 yd	Polyester Film	Silicone

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 57.96

General part information

Masking Tape Silicone Adhesive Blue 4.92" (125.00mm) X 216' (66.0m) 72 yds
