Specification	Q2-Z-1/4-01-QB6IN-20

Color	Black
Features	Flame Retardant
Inner Diameter - Recovered	0.125 in
Inner Diameter - Supplied	0.25 in
Length	0.5 ft
Material	Polyolefin (PO)
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Recovered Wall Thickness	0.022 in
Shelf Life	144 Months
Shrink Temperature	70 °C
Shrinkage Ratio	2
Storage/Refrigeration Temperature (Maximum)	104 °F
Storage/Refrigeration Temperature (Minimum)	-50 °F
Type	Flexible, Tubing

Q2-Z-1/4 Series

Part	Color	Shrink Temperature	Recovered Wall Thickness	Type	Inner Diameter - Recovered	Storage/Refrigeration Temperature (Minimum)	Storage/Refrigeration Temperature (Maximum)	Features	Length	Shrinkage Ratio	Inner Diameter - Supplied	Material	Shelf Life	Operating Temperature (Max)	Operating Temperature (Min)
Qualtek Q2-Z-1/4-01-QB48IN-25	Black	70 °C	0.022 in	Flexible Tubing	0.125 in	-50 °F	104 °F	Flame Retardant	48 in	2	0.25 in	Polyolefin (PO)	144 Months	125 °C	-55 °C
Qualtek Q2-Z-1/4-01-QB6IN-20	Black	70 °C	0.022 in	Flexible Tubing	0.125 in	-50 °F	104 °F	Flame Retardant	0.5 ft	2	0.25 in	Polyolefin (PO)	144 Months	125 °C	-55 °C
Qualtek Q2-Z-1/4-01-MS100FT	Black	70 °C	0.022 in	Flexible Tubing	0.125 in	-50 °F	104 °F	Flame Retardant	100 ft	2	0.25 in	Polyolefin (PO)	144 Months	125 °C	-55 °C
