PAA10-10

Active

TT Electronics/Power Partners Inc.

AC/DC CONVERTER 5V 10W

Search across all available documentation for this part.

Active

TT Electronics/Power Partners Inc.

AC/DC CONVERTER 5V 10W

Technical Specifications

Parameters and characteristics for this part

Specification	PAA10-10

Applications	Household Appliances, ITE (Commercial)
Approval Agency	CB, cURus, CE
Current - Output (Max) [Max]	2 A
Efficiency	81 %
Features	Universal Input
Line Regulation	±0.2%
Load Regulation	1 %
Mounting Type	Through Hole
Number of Outputs	1
Package / Case	5-SIP Module
Power (Watts)	10 W
Size / Dimension	27.5 mm, 37 mm, 20 mm
Size / Dimension [x]	1.46 in
Size / Dimension [y]	1.08 in
Size / Dimension [z]	0.79 in
Type	Enclosed
Voltage - Input [Max]	305 VAC, 430 VDC
Voltage - Input [Min]	127 VDC, 90 VAC
Voltage - Output 1	5 V

AC/DC CONVERTER 5V 10W

Part	Power (Watts)	Package / Case	Voltage - Output 1	Load Regulation	Applications	Current - Output (Max) [Max]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension	Size / Dimension [x]	Approval Agency	Mounting Type	Type	Efficiency	Features	Line Regulation	Number of Outputs	Voltage - Input [Max]	Voltage - Input [Min]
TT Electronics/Power Partners Inc. PAA10-10	10 W	5-SIP Module	5 V	1 %	Household Appliances, ITE (Commercial)	2 A	1.08 in	0.79 in	20 mm, 27.5 mm, 37 mm	1.46 in	CB, CE, cURus	Through Hole	Enclosed	81 %	Universal Input	±0.2%	1	305 VAC, 430 VDC	90 VAC, 127 VDC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 5V 2A 90 ~ 305 VAC, 127 ~ 430 VDC Input
