FN7514-32-M4
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 0.1UF 20% 1KV AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
FN7514-32-M4
ActiveTE Connectivity Raychem Cable Protection
CAP FEEDTHRU 0.1UF 20% 1KV AXIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | FN7514-32-M4 |
|---|---|
| Capacitance | 100000 pF |
| Current | 32 A |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Axial - Threaded Terminals |
| Ratings | Y2 |
| Size / Dimension [diameter] | 26.95 mm |
| Size / Dimension [diameter] | 1.061 " |
| Size / Dimension [x] | 77 mm |
| Size / Dimension [x] | 3.031 in |
| Thread Size | M16x1 |
| Tolerance | 20 % |
| Voltage - Rated | 1 kV |
| Voltage - Rated | 1000 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 91.80 | |
| 10 | $ 72.96 | |||
| 40 | $ 66.16 | |||
| 80 | $ 63.60 | |||
Description
General part information
FN7514 Series
0.1 µF Feed Through Capacitor 1000V (1kV) 32 A 0.58mOhm (Typ) Axial - Threaded Terminals
