PH1200A280-24

Active

TDK-LAMBDA

ISOLATED DC/DC CONVERTERS - THROUGH HOLE 1200W 24V 50A

Search across all available documentation for this part.

Active

TDK-LAMBDA

ISOLATED DC/DC CONVERTERS - THROUGH HOLE 1200W 24V 50A

Technical Specifications

Parameters and characteristics for this part

Specification	PH1200A280-24

Applications	ITE (Commercial)
Approval Agency	UKCA, CE
Control Features	Active Low, Enable
Current - Output (Max) [Max]	50 A
Efficiency	94 %
Features	Remote On/Off, Adjustable Output, Baseplate, Remote Sense
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Package / Case	Full Brick
Power (Watts)	1200 W
Size / Dimension [x]	4.6 "
Size / Dimension [x]	116.8 mm
Size / Dimension [y]	2.4 "
Size / Dimension [y]	61 mm
Size / Dimension [z]	0.5 in
Size / Dimension [z]	12.7 mm
Standard Number	62368-1
Supplier Device Package	Full Brick
Type	Isolated Module
Voltage - Input (Max) [Max]	425 V
Voltage - Input (Min) [Min]	200 V
Voltage - Isolation	3000 V
Voltage - Output 1	24 V

Isolated DC/DC Converters - Through Hole 1200W 24V 50A

Part	Features	Voltage - Isolation	Power (Watts)	Package / Case	Number of Outputs	Voltage - Output 1	Mounting Type	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Control Features	Type	Voltage - Input (Min) [Min]	Supplier Device Package	Standard Number	Approval Agency	Applications	Current - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Efficiency
TDK-LAMBDA PH1200A280-24	Adjustable Output Baseplate Remote On/Off Remote Sense	3000 V	1200 W	Full Brick	1	24 V	Through Hole	0.5 in	4.6 "	116.8 mm	12.7 mm	2.4 "	61 mm	Active Low Enable	Isolated Module	200 V	Full Brick	62368-1	CE UKCA	ITE (Commercial)	50 A	-40 °C	100 °C	425 V	94 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 530.00
		10	$ 517.00
Newark	Each	1	$ 537.32
Sager	N/A	1	$ 530.00
		10	$ 517.00
		25	$ 511.00
		50	$ 506.00

General part information

Isolated DC/DC Converters - Through Hole 1200W 24V 50A
