SQT-102-02-L-D

Active

Samtec Inc.

CONNECTOR, RCPT, 4POS, 2ROW, 2MM ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

Documents2.00 mm Shrouded Terminal Strip Datasheet +4

SQT-102-02-L-D

Active

Samtec Inc.

CONNECTOR, RCPT, 4POS, 2ROW, 2MM ROHS COMPLIANT: YES

Deep-Dive with AI

Documents2.00 mm Shrouded Terminal Strip Datasheet +4

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	SQT-102-02-L-D

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Length - Post	15.24 mm
Contact Length - Post	0.6 in
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Forked
Current Rating (Amps)	5.1 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	6.35 mm
Insulation Height	0.25 in
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	4
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Row Spacing - Mating	0.079 in
Row Spacing - Mating	2 mm
Style	Board to Board, Cable
Termination	Solder

SQT-102 Series

Part	Style	Contact Length - Post	Contact Length - Post	Pitch - Mating [x]	Pitch - Mating [x]	Row Spacing - Mating	Row Spacing - Mating	Insulation Material	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Number of Positions	Insulation Height	Insulation Height	Material Flammability Rating	Contact Finish - Mating	Contact Shape	Number of Rows	Mounting Type	Contact Material	Number of Positions Loaded	Contact Finish - Post	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Contact Type	Termination	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions Loaded
Samtec Inc. SQT-102-01-L-D	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black	10 çin	0.25 çm	Push-Pull	4	6.35 mm	0.25 in	UL94 V-0	Gold	Square	2	Through Hole	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder
Samtec Inc. SQT-102-02-F-S	Board to Board Cable	0.6 in	15.24 mm	0.079 in	2 mm			Liquid Crystal Polymer (LCP)	Black			Push-Pull	2	6.35 mm	0.25 in	UL94 V-0	Gold	Square	1	Through Hole	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder	Flash
Samtec Inc. SQT-102-01-G-D	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black	20 µin	0.51 µm	Push-Pull	4	6.35 mm	0.25 in	UL94 V-0	Gold	Square	2	Through Hole	Phosphor Bronze	All	Gold	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder		3 µin	0.076 µm
Samtec Inc. SQT-102-03-L-D-002	Board to Board Cable	0.208 in	5.28 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black	10 çin	0.25 çm	Push-Pull	4	6.35 mm	0.25 in	UL94 V-0	Gold	Square	2	Through Hole	Phosphor Bronze		Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder				3
Samtec Inc. SQT-102-01-G-S-RA	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm			Liquid Crystal Polymer (LCP)	Black	20 µin	0.51 µm	Push-Pull	2	2 mm	0.079 in	UL94 V-0	Gold	Square	1	Through Hole Right Angle	Phosphor Bronze	All	Gold	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder		3 µin	0.076 µm
Samtec Inc. SQT-102-01-S-D	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black	30 Áin	0.76 Ám	Push-Pull	4	6.35 mm	0.25 in	UL94 V-0	Gold	Square	2	Through Hole	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder
Samtec Inc. SQT-102-01-F-5	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black			Push-Pull	10	6.35 mm	0.25 in	UL94 V-0	Gold	Square	5	Through Hole	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder	Flash
Samtec Inc. SQT-102-02-L-D	Board to Board Cable	0.6 in	15.24 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black	10 çin	0.25 çm	Push-Pull	4	6.35 mm	0.25 in	UL94 V-0	Gold	Square	2	Through Hole	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder
Samtec Inc. SQT-102-01-F-Q	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm	0.079 in	2 mm	Liquid Crystal Polymer (LCP)	Black			Push-Pull	8	6.35 mm	0.25 in	UL94 V-0	Gold	Square		Through Hole	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder	Flash
Samtec Inc. SQT-102-01-L-S-RA	Board to Board Cable	0.09 "	2.29 mm	0.079 in	2 mm			Liquid Crystal Polymer (LCP)	Black	10 çin	0.25 çm	Push-Pull	2	2 mm	0.079 in	UL94 V-0	Gold	Square	1	Through Hole Right Angle	Phosphor Bronze	All	Tin	Receptacle	-55 °C	125 °C	5.1 A	Forked	Solder

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2.06
Newark	Each	1	$ 1.72
		10	$ 1.55
		100	$ 1.33
		500	$ 1.12
		1000	$ 0.95
		2500	$ 0.88
		5000	$ 0.85
		10000	$ 0.83
