37112 002500

Active

Belden Inc.

HOOK-UP STRND 12AWG RED 500'

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 12AWG RED 500'

Technical Specifications

Parameters and characteristics for this part

Specification	37112 002500

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	30 AWG
Conductor Strand [custom]	65
Features	High Temperature
Jacket (Insulation) Diameter [diameter]	4.83 mm
Jacket (Insulation) Diameter [diameter]	0.19 in
Jacket (Insulation) Material	Ethylene Propylene Terpolymer Rubber (EPDM)
Jacket (Insulation) Thickness	1.3 mm
Jacket (Insulation) Thickness	0.051 in
Jacket Color	Red
Length [x]	500 '
Length [x]	152.4 m
Ratings	UL Style 3340/3374
Voltage	600 V
Wire Gauge	12 AWG

Part	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Wire Gauge	Features	Conductor Material	Voltage	Ratings	Length [x]	Length [x]	Jacket (Insulation) Material	Length	Length
Belden Inc. 37112 002500	30 AWG	65	4.83 mm	0.19 in	Red	Hook-Up	1.3 mm	0.051 in	12 AWG	High Temperature	Copper Tinned	600 V	UL Style 3340/3374	500 '	152.4 m	Ethylene Propylene Terpolymer Rubber (EPDM)
Belden Inc. 37112 0103000	30 AWG	65	4.83 mm	0.19 in	Black	Hook-Up	1.3 mm	0.051 in	12 AWG	High Temperature	Copper Tinned	600 V	UL Style 3340/3374			Ethylene Propylene Terpolymer Rubber (EPDM)	914.4 m	3000 ft

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1	$ 1474.79

General part information

12 AWG Hook-Up Wire 65/30 Red 600V 500.0' (152.4m)
