1-36-2302-20

Active

TapeCase

TAPE POLYETHYLENE FILM NATURAL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

1-36-2302-20

Active

TapeCase

TAPE POLYETHYLENE FILM NATURAL

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	2	$ 198.42
		20	$ 146.84
		60	$ 134.21

Description

General part information

2302 Series

Polyethylene Film Tape Acrylic Adhesive Natural X

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	1-36-2302-20	2302 Series

Adhesive	Acrylic	Acrylic
Backing, Carrier	UHMW Polyolefin Film	UHMW Polyolefin Film
Color	Natural	Natural
Tape Type	Polyethylene Film	Polyethylene Film
Thickness	0.508 mm	0.254 - 0.508 mm
Thickness	0.02 in	0.01 - 0.02 in
Thickness	0.508 mm	0.508 - 10 mm
Thickness - Adhesive	1.5 mils	1.5 mils
Thickness - Adhesive	0.0015 in	0.0015 in
Thickness - Adhesive	0.038 mm	0.038 mm
Thickness - Backing, Carrier	0.02 "	0.01 - 0.02 "
Thickness - Backing, Carrier	0.508 mm	0.254 - 0.508 mm
Thickness - Backing, Carrier	20 mils	10 - 20 mils
Usage	General Purpose	General Purpose

2302 Series

TAPE POLYETHYLENE FILM NATURAL

...

Part	Backing, Carrier	Adhesive	Usage	Color	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Tape Type	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Thickness	Thickness	Thickness
TapeCase 1-36-2302-20	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.02 "	0.508 mm	20 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.508 mm	0.02 in	0.508 mm
TapeCase 10-5-2302-10	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.01 "	0.254 mm	10 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.254 mm	0.01 "	10 mils
TapeCase 0.375-5-2302-10 (PK2)	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.01 "	0.254 mm	10 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.254 mm	0.01 "	10 mils
TapeCase 0.25-36-2302-20	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.02 "	0.508 mm	20 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.508 mm	0.02 in	0.508 mm
TapeCase 2.5-36-2302-10	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.01 "	0.254 mm	10 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.254 mm	0.01 "	10 mils
TapeCase 3/4-5-2302-10	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.01 "	0.254 mm	10 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.254 mm	0.01 "	10 mils
TapeCase 1.5-36-2302-10	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.01 "	0.254 mm	10 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.254 mm	0.01 "	10 mils
TapeCase 1.25-36-2302-10	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.01 "	0.254 mm	10 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.254 mm	0.01 "	10 mils
TapeCase 9-36-2302-20	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.02 "	0.508 mm	20 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.508 mm	0.02 in	0.508 mm
TapeCase 1.625-36-2302-20	UHMW Polyolefin Film	Acrylic	General Purpose	Natural	0.02 "	0.508 mm	20 mils	Polyethylene Film	1.5 mils	0.0015 in	0.038 mm	0.508 mm	0.02 in	0.508 mm
