SRP1250-1R2M

Active

Bourns Inc.

SURFACE MOUNT POWER INDUCTOR, SRP1250 SERIES, 1.2 H, 20%, SHIELDED, 3300 OHM, 27 A

Search across all available documentation for this part.

Active

Bourns Inc.

SURFACE MOUNT POWER INDUCTOR, SRP1250 SERIES, 1.2 H, 20%, SHIELDED, 3300 OHM, 27 A

Technical Specifications

Parameters and characteristics for this part

Part	DC Resistance (DCR) [Max]	Mounting Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Type	Inductance	Inductance Frequency - Test	Material - Core	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Shielding	Current - Saturation (Isat)	Tolerance	Current Rating (Amps)
Bourns Inc. SRP1250-100M	25.5 mOhm	Surface Mount	0.547 in	13.9 mm	0.531 in	13.5 mm	Drum Core Wirewound	10 µH	100 kHz	Iron	5.9 mm	0.232 "	-55 °C	150 °C	Nonstandard	Shielded	16 A	20 %
Bourns Inc. SRP1250-1R0M	2.5 mOhm	Surface Mount	0.547 in	13.9 mm	0.531 in	13.5 mm	Drum Core Wirewound	1 µH	100 kHz	Iron	5.9 mm	0.232 "	-55 °C	150 °C	Nonstandard	Shielded	50 A	20 %	29 A
Bourns Inc. SRP1250-1R2M	3.3 mOhm	Surface Mount	0.547 in	13.9 mm	0.531 in	13.5 mm	Drum Core Wirewound	1.2 µH	100 kHz	Iron	5.9 mm	0.232 "	-55 °C	150 °C	Nonstandard	Shielded	49 A	20 %	27 A
Bourns Inc. SRP1250-6R8M	18.5 mOhm	Surface Mount	0.547 in	13.9 mm	0.531 in	13.5 mm	Drum Core Wirewound	6.8 µH	100 kHz	Iron	5.9 mm	0.232 "	-55 °C	150 °C	Nonstandard	Shielded	21 A	20 %	11 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1.2 µH Shielded Drum Core, Wirewound Inductor 27 A 3.3mOhm Max Nonstandard
