Specification	S18LGRYP

Current	25 mA
Ingress Protection	IP69K, NEMA 4X, IP67
Lamp Color	Green, Yellow, Red
Lens Style	Round, Flat Top
Lens Transparency	Diffused
Millicandela Rating (Green)	4.1 mcd
Millicandela Rating (Red)	1.1 mcd
Millicandela Rating (Yellow)	0.8 mcd
Millicandela Rating Colors	Yellow, Red, Green
Panel Cutout Dimension	0.709 "
Panel Cutout Shape	Round
Ratings	DC
Termination Style	Wire Leads
Type	LED
Voltage (Max)	30 V
Voltage (Min)	10 V

S18LG Series

Part	Viewing Angle	Panel Cutout Shape	Lens Diameter	Ratings	Type	Current	Ingress Protection	Termination Style	Lens Style	Voltage (Max)	Voltage (Min)	Lamp Color	Millicandela Rating Colors	Millicandela Rating (Red)	Millicandela Rating (Green)	Millicandela Rating (Yellow)	Panel Cutout Dimension	Lens Transparency	Millicandela Rating
BANNER ENGINEERING S18LGRXPQP-807856	180 °	Round	16 mm	DC	LED	25 mA	IP67 IP69K	Quick Connect	Flat Top Round	30 V	10 V	Green Red
BANNER ENGINEERING S18LGYXNQ	180 °	Round	16 mm	DC	LED	25 mA	IP67 IP69K	Quick Connect	Flat Top Round	30 V	10 V	Green Yellow
BANNER ENGINEERING S18LGRYPQ		Round		DC	LED	25 mA	IP67 IP69K NEMA 4X	Quick Connect	Flat Top Round	30 V	10 V	Green Red Yellow	Green Red Yellow	1.1 mcd	4.1 mcd	0.8 mcd	0.709 "	Diffused
BANNER ENGINEERING S18LGROPQ	180 °	Round	16 mm	DC	LED	25 mA	IP67 IP69K	Quick Connect	Flat Top Round	30 V	10 V	Green Orange Red
BANNER ENGINEERING S18LGXXPQ		Round		DC	LED	25 mA	IP67 IP69K NEMA 4X	Quick Connect	Flat Top Round	30 V	10 V	Green					0.709 "	Diffused	4.1 mcd
BANNER ENGINEERING S18LGRXPQ		Round		DC	LED	25 mA	IP67 IP69K NEMA 4X	Quick Connect	Flat Top Round	30 V	10 V	Green Red	Green Red	1.1 mcd	4.1 mcd		0.709 "	Diffused
BANNER ENGINEERING S18LGRYNT	180 °	Round	16 mm	DC	LED	25 mA	IP67 IP69K	Screw Terminal	Flat Top Round	30 V	10 V	Green Red Yellow
BANNER ENGINEERING S18LGXRPQ		Round		DC	LED	25 mA	IP67 IP69K NEMA 4X	Quick Connect	Flat Top Round	30 V	10 V	Green Red	Green Red	1.1 mcd	4.1 mcd		0.71 "	Clear
BANNER ENGINEERING S18LGRYPQP		Round		DC	LED	25 mA	IP67 IP69K NEMA 4X	Wire Leads	Flat Top Round	30 V	10 V	Green Red Yellow	Green Red Yellow	1.1 mcd	4.1 mcd	0.8 mcd	0.71 "	Clear
BANNER ENGINEERING S18LGXBPQ	180 °	Round	16 mm	DC	LED	25 mA	IP67 IP69K	Quick Connect	Flat Top Round	30 V	10 V	Blue Green
