MPLCV1054L100
ActiveKEMET
POWER INDUCTOR (SMD), AEC-Q200, 10 ΜH, 7.1 A, SHIELDED, 12 A, MPLCV SERIES
Deep-Dive with AI
Search across all available documentation for this part.
MPLCV1054L100
ActiveKEMET
POWER INDUCTOR (SMD), AEC-Q200, 10 ΜH, 7.1 A, SHIELDED, 12 A, MPLCV SERIES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MPLCV1054L100 |
|---|---|
| Current Rating (Amps) | 7.1 A |
| DC Resistance (DCR) | 25 mOhm |
| Height - Seated (Max) [Max] [z] | 5.4 mm |
| Height - Seated (Max) [Max] [z] | 0.213 in |
| Inductance | 10 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal Composite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension [x] | 11.5 mm |
| Size / Dimension [x] | 0.453 " |
| Size / Dimension [y] | 0.394 in |
| Size / Dimension [y] | 10 mm |
| Tolerance | 20 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.19 | |
| 10 | $ 2.67 | |||
| 25 | $ 2.44 | |||
| 50 | $ 2.09 | |||
| 100 | $ 1.92 | |||
| 250 | $ 1.86 | |||
| 500 | $ 1.80 | |||
| Digi-Reel® | 1 | $ 3.19 | ||
| 10 | $ 2.67 | |||
| 25 | $ 2.44 | |||
| 50 | $ 2.09 | |||
| 100 | $ 1.92 | |||
| 250 | $ 1.86 | |||
| 500 | $ 1.80 | |||
| Tape & Reel (TR) | 1000 | $ 1.48 | ||
| 2000 | $ 1.44 | |||
| Newark | Each (Supplied on Full Reel) | 2000 | $ 1.81 | |
| 4000 | $ 1.68 | |||
| 8000 | $ 1.57 | |||
| 12000 | $ 1.51 | |||
| 20000 | $ 1.49 | |||
Description
General part information
MPLCV1054 Series
10 µH Shielded Inductor 7.1 A 25mOhm Nonstandard
