RN143-6-02-1M8
ActiveTE Connectivity Raychem Cable Protection
CMC 1.8MH 6A 2LN TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
RN143-6-02-1M8
ActiveTE Connectivity Raychem Cable Protection
CMC 1.8MH 6A 2LN TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | RN143-6-02-1M8 |
|---|---|
| Approval Agency | ENEC, UR, VDE |
| Current Rating (Max) [Max] | 6 A |
| DC Resistance (DCR) (Max) | 20 mOhm |
| Filter Type | Power Line |
| Height (Max) [Max] | 0.787 in |
| Height (Max) [Max] | 20 mm |
| Inductance @ Frequency | 1.8 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Horizontal |
| Package / Case | 4 Lead |
| Size / Dimension [x] | 1.303 in |
| Size / Dimension [x] | 33.1 mm |
| Size / Dimension [y] | 1.28 in |
| Size / Dimension [y] | 32.5 mm |
| Voltage Rating - AC | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 4.51 | |
| 10 | $ 3.50 | |||
| 25 | $ 3.16 | |||
| 50 | $ 2.93 | |||
| 100 | $ 2.71 | |||
| 250 | $ 2.57 | |||
Description
General part information
RN143 Series
1.8 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 6A DCR 20mOhm (Typ)
