6EDL04N06PCX1SA1

Active

Infineon Technologies

EICEDRIVER™ 600 V THREE PHASE DRIVER IC WITH TYPICAL 0.17 A SOURCE AND 0.375 A SINK OUTPUT CURRENTS. IT COMES WITH A FUNCTIONAL LEVELSHIFT PACKAGE AND WORKS WITH MOSFETS.

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

6EDL04N06PCX1SA1

Active

Infineon Technologies

EICEDRIVER™ 600 V THREE PHASE DRIVER IC WITH TYPICAL 0.17 A SOURCE AND 0.375 A SINK OUTPUT CURRENTS. IT COMES WITH A FUNCTIONAL LEVELSHIFT PACKAGE AND WORKS WITH MOSFETS.

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	6EDL04N06PCX1SA1

Channel Type	3-Phase
Driven Configuration	Half-Bridge
Gate Type	IGBT
High Side Voltage - Max (Bootstrap) [Max]	600 V
Input Type	Non-Inverting
Logic Voltage - VIL, VIH [custom]	1.1 V
Logic Voltage - VIL, VIH [custom]	1.7 V
Mounting Type	Surface Mount
Number of Drivers	6
Operating Temperature [Max]	125 ¯C
Operating Temperature [Min]	-40 °C
Package / Case	Die
Rise / Fall Time (Typ) [custom]	60 ns
Rise / Fall Time (Typ) [custom]	26 ns
Supplier Device Package	Chip
Voltage - Supply [Max]	17.5 V
Voltage - Supply [Min]	13 V

6EDL04 Series

Part	High Side Voltage - Max (Bootstrap) [Max]	Driven Configuration	Package / Case	Channel Type	Mounting Type	Gate Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply [Max]	Voltage - Supply [Min]	Number of Drivers	Supplier Device Package	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Input Type	Logic Voltage - VIL, VIH [custom]	Logic Voltage - VIL, VIH [custom]	Package / Case	Package / Case [y]	Package / Case [x]
Infineon Technologies 6EDL04N06PCX1SA1	600 V	Half-Bridge	Die	3-Phase	Surface Mount	IGBT	-40 °C	125 ¯C	17.5 V	13 V	6	Chip	60 ns	26 ns	Non-Inverting	1.1 V	1.7 V
Infineon Technologies 6EDL04I06PCX1SA1	600 V	Half-Bridge	Die	3-Phase	Surface Mount	IGBT	-40 °C	125 ¯C	17.5 V	13 V	6	Chip	60 ns	26 ns	Non-Inverting	1.1 V	1.7 V
Infineon Technologies 6EDL04N02PRXUMA1	200 V	Half-Bridge	28-TSSOP	3-Phase	Surface Mount		-40 °C	125 ¯C	17.5 V	10 VDC	6	PG-TSSOP-28	60 ns	26 ns	Non-Inverting	1.1 V	1.7 V	0.173 in	4.4 mm
Infineon Technologies 6EDL04I06NCX1SA1	600 V	Half-Bridge	Die	3-Phase	Surface Mount	IGBT	-40 °C	125 ¯C	17.5 V	13 V	6	Chip	60 ns	26 ns	Non-Inverting	1.1 V	1.7 V
Infineon Technologies 6EDL04N06PTXUMA1	620 V	Half-Bridge	28-SOIC	3-Phase	Surface Mount		-40 °C	125 ¯C	17.5 V	10 VDC	6	PG-DSO-28	60 ns	26 ns	Non-Inverting	1.1 V	1.7 V		7.5 mm	0.295 in
Infineon Technologies 6EDL04I06PTXUMA1	600 V	Half-Bridge	28-SOIC	3-Phase	Surface Mount		-40 °C	125 ¯C	17.5 V	13 V	6	PG-DSO-28	60 ns	26 ns	Non-Inverting	1.1 V	1.7 V		7.5 mm	0.295 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 3.09
		10	$ 2.78
		25	$ 2.63
		100	$ 2.28
		250	$ 2.16
		500	$ 1.94
		1000	$ 1.63
		2500	$ 1.55
		5000	$ 1.49

Description

General part information

6EDL04 Series

EiceDRIVER™ 600 V three phasegate driver ICbare die forMOS-transistorsandIGBTswith 0.17 A source and 0.375 A sink currents and LS-SOI technology.
